Automatic Fam Tape Kiss Full Cutting Machine
|
Model |
HX-500B |
|
Cutting Length |
0.1~9999.9mm |
|
Cutting Width |
1~500mm |
|
Power |
1200W |
|
Voltage |
220V/380V |
|
N.W./GW. |
240/260kg |
|
Measurement |
980x1450x1070mm |
1. Max material width: 500mm;
2. Tolerance: 0.05mm, Precision: 0.1mm;
3. Material thickness range: 0.5mm-15mm;
4. A conbination of HMI, PLC and pneumatic device;
5. This cutting foam machine adds automatic unwinding system;
6. Cutting length is accurate with a servo motor;
7. Operation is easy with a touch screen in English display;
8. Waste rate is low;
9. Manufacturing experience: 10years;
10. Export experience: 5 years.
Additional functions:
1. You can choose a kiss cutting knife to achieve kiss cut.
2. This machine can set a procedure of several kiss-cuts and one full-cut;
3. Five different lengths can be set at the same time as you need;
4. Different quantities and cycle times can be set to meet your various needs;
Size cutting for heat shrinking tube, flat cable, PVC sleeve, insulation paper, two-sided tape, hook and loop fastener , cotton belt, zipper, release paper, etc.
1. A warranty period of 12 months
2. A prompt reply within 24 hours
3. Free operation training before delivering.
Partial simples from this cutting foam machine:
Kunshan Hexin Precision Company is a collection of produciton,research and development, sales and service as one fo professional electronic machinery manufacturing enterprises. We specialized in microcomputer slicing machines, cutting machines, slitting machines, laminating machines and die-cuting machines for many years. Our company have obtained 11 paternts patents and passed the SGS factory qualification ceritficaiton adn the European Union CE certification. In 2013, we have got "national high-tech enterprise/" Our products are exported to Europe, America, Southeast Asia, the Middle East, Singapore, India,Thailand agents at abroad, our products enjoy a good reputaiton at domestic and international market.
1. Q: Are you a factory or trading company?
A: We are a factory and manufacturer
2. Q: Where is your factory located in ? How can I visit there?
A: Our factory is located in Kunshan which is very near from Shanghai, and our detailed address is: Factory 9, No. 157, Wulian Road, Yushan Town,
Kunshan, Suzhou, Jiangsu, China. If you fly to Shanghai hongqiao airport or Pudong airport, we can pick you up by car from there. We welcome all our clients, home and abroad, to visit us.
3. Q: what are your main products?
A: Our main products are belt cutting machines, slitting machines, sheeting machines, laminating machines and die cutting machines.
4.Q: Which industries can use your machines ?
A: All industries need to cut (include full cutting and kiss-cutting), slit, laminate, die cut raw materials can use our machines.
5.Q: How to control the quality in your factory ?
A: Quality is priority. We control the quality of our products strictly, from the incoming materials to the finished products. Our factory has obtained CE & ISO Certification
6. Q:If there are no machines available from your list, could we customize non-standard machines from you ?
A: Yes, we have our own professional design engineers, and can customize products according to your requirements.
