Customized Large-Scale Pepper Drying Equipment Automatic Continuous Multi-Layer Belt Dryer Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Vegetable Salad Washing Machine Bubble Spray Olive Vegetable Washing Machine
-
Hot Sale Roller Brush Ginger Washing Machine
-
2021 Newly Assembly Line Equipment Transferring Material Conveyor
-
Assembly Line Equipment Industrial Sorting Conveyor Fruit Conveyor Belt
-
Easy to Operate Multifunctional Chinese Vegetable Cutter Root Fruit Vegetables Cutter Electric
-
Automatic Fruit and Vegetable Cutting Machine Leaf Vegetable Spinach Cutting Machine/Spinach/ Parsley/Lettuce Cutter Price
Product Description
Product Description
Introduction
The equipment has uniform drying, fast speed and high efficiency. It can realize automatic temperature control and automatic damp removal. It can keep the dried material in a better shape, maintain the color and shape of the dried material, and improve the quality of the product. Electric heating is adopted, which can realize automatic temperature control, automatic damp discharge, and adjustable damp discharge speed; the temperature, time and exhaust of this equipment can be set freely.
Applicable materials for small drying oven: raw materials for pharmaceutical, chemical, food, light industry and heavy industry.
The equipment has uniform drying, fast speed and high efficiency. It can realize automatic temperature control and automatic damp removal. It can keep the dried material in a better shape, maintain the color and shape of the dried material, and improve the quality of the product. Electric heating is adopted, which can realize automatic temperature control, automatic damp discharge, and adjustable damp discharge speed; the temperature, time and exhaust of this equipment can be set freely.
Applicable materials for small drying oven: raw materials for pharmaceutical, chemical, food, light industry and heavy industry.
Product Name | Three Layer Drying Machine | Power | Customized |
Brand | LONKIA | Voltage | 220/380v |
Material | SUS304 | Place of Product | Shandong Province,China |
Capacity | Customized | Modes of packing | Packed in Standard cartons |
Size | Customized | After sale service | Spare and wearing parts provided |
Principle of Mesh-Belt Drier:
The materials are uniformly put on the mesh-belt by the material charger. The mesh-belt uses generally 12-60 mesh stainless steel wire net and it is drawn and moved inside the drier by a transmission device. The drier is composed of several units. For each unit, the hot air is circulated separately. Some exhausted gas is discharged with a special moisture elimination blower. The waste gas is controlled through an adjustment valve. The hot air passes through the mesh-belt covered with the material from the top to the bottom of from the the bottom to the top and this will complete the heat and mass transfer process. This process will bring the material water away. The mesh-belt moves slowly, running speed can be freely adjusted according to the material temperature.
The final products after the drying will fall into the material collector continuously. The top and low circulation units can be freely equipped according to the users’ demand. The unit number can be selected according to the demand.
The materials are uniformly put on the mesh-belt by the material charger. The mesh-belt uses generally 12-60 mesh stainless steel wire net and it is drawn and moved inside the drier by a transmission device. The drier is composed of several units. For each unit, the hot air is circulated separately. Some exhausted gas is discharged with a special moisture elimination blower. The waste gas is controlled through an adjustment valve. The hot air passes through the mesh-belt covered with the material from the top to the bottom of from the the bottom to the top and this will complete the heat and mass transfer process. This process will bring the material water away. The mesh-belt moves slowly, running speed can be freely adjusted according to the material temperature.
The final products after the drying will fall into the material collector continuously. The top and low circulation units can be freely equipped according to the users’ demand. The unit number can be selected according to the demand.
FAQ
Shipping&Packing
Standard export wooden case packing, fit for multiple handing and long distance marine shipping.
delivery Time
For stock type, we can send within 48hrs after confirming order.
For customized type , delivery date need to be negotiated before taking order.
Standard export wooden case packing, fit for multiple handing and long distance marine shipping.
delivery Time
For stock type, we can send within 48hrs after confirming order.
For customized type , delivery date need to be negotiated before taking order.
Our Services & Strength
Manufacturer service:
1.Provide high quality goods according to your demand;
2.Keep quality superior forever;
3.Finish the deal with reasonable price.
After-sale service:
1.Offer service for your project and factory building;
2.Repair&maintenance in the guarantee period;
3.Installation and clerks training;
4.Spare and wearing parts provided for free or factory direct price;
5.Ask feedback from you to serve you better in the future;
Other service:
1.Timely response online by WhatsApp, Skype, Wechat or Trade Manager;
2.Keep in touch by Email or phone calls;
3.Standard export package or as your required;
4.Fast and punctual delivery.
1.Provide high quality goods according to your demand;
2.Keep quality superior forever;
3.Finish the deal with reasonable price.
After-sale service:
1.Offer service for your project and factory building;
2.Repair&maintenance in the guarantee period;
3.Installation and clerks training;
4.Spare and wearing parts provided for free or factory direct price;
5.Ask feedback from you to serve you better in the future;
Other service:
1.Timely response online by WhatsApp, Skype, Wechat or Trade Manager;
2.Keep in touch by Email or phone calls;
3.Standard export package or as your required;
4.Fast and punctual delivery.
