Standards: GB/T20123-2006, ISO15350:2000
This high-frequency infrared carbon and sulfur analyzer can quickly and accurately determine the content of carbon and sulfur in organic and other materials (by work with high-frequency induction combustion furnace). Such as ferroalloys, stainless steel, carbon steel, alloy steel, cast iron, ductile iron, non-ferrous metals, rare earth metals, cement, ore, coke, coal, slag, ceramics, catalysts, foundry core sand, iron ore.
Main features
1. The high-frequency furnace adopts radio frequency heating technology to ensure the consistency of each combustion and the stability of the test;
2. Adopting Germany carbon and sulfur analysis technology, uses high-performance narrow-band filters to avoid the interference of high carbon on sulfur;
3. International renowned high-precision infrared pyroelectric detector guaranteed the precision and accuracy of high-carbon and ultra-low-carbon measurement;
4. The infrared carbon and sulfur absorption device adopts Switzerland made aviation synchronous motor, which can be used continuously for 100,000 hours without failure;
5. Main board design and modular application, combined with temperature, pressure and flow compensation technology, guaranteed the consistency of the analysis results;
6. The high quality solenoid valve can guarantee 200,000 times opening without failure, ensure reliable running of the gas circuit.
7. Military-grade motherboard design and modular application, high reliability;
8. Optical fiber transmission interface, strong anti-interference, more stable data transmission;
9. Fully automatic burner design, automatic double-sided reverse blowing, effectively remove the dust after combustion, especially suitable for the stability of the analysis of dusty samples such as raw materials;
10. More advanced and easy-to-use analysis software, open database, convenient for users to manage analysis data;
Specifications
Measuring range |
Carbon: 0.00001%～99.999% Sulfur: 0.00001%～99.999% |
Analysis accuracy |
Carbon RSD ≤0.5% Sulfur RSD ≤1.0% |
Sensitivity (reading) |
0.1ppm |
Analysis time |
25-60 seconds (adjustable) generally around 35 seconds. |
Electronic balance |
Weighing range: 0-120g Reading accuracy: 0.0001g |
High-frequency furnace |
2.5KVA Frequency: 18-20MHz |
Working power |
220VAC, 50HZ. |
