Vertical Dome type 24 48 96 144 288 core fiber cable joint box Fiber optic splice closure
- 1000 per Month
- T/T Credit Card
- Network Equipment Fiber Optic Dome splice Closure with PLC Splitter
- FTTH (ofsc-012) max 144core fiber optic Dome splice closure
- Up to 144 ports vertical type splice closure,Fiber Optic Splice Closure(FOSC--24 to 576 fiber),2 inlet 2outlet Horizontal Fiber
- Outdoor Horizontal in line type 12 24 36 48 96 core fiber optic splicing closure enclosure
- 24 48 96 144 288 Core Vertical Dome Type Fiber Cable Joint Box Black Fiber Optic Splice Closure IP68 Aerial ISO9001, ROHS CN;GUA
- Fiber Optical Splice Closure,Dome type,Max 216 core,Manufacturer
Product Description
Vertical Dome type 24 48 96 144 288 core fiber cable joint box Fiber optic splice closure
APPLICATION
and broadband
FEATURES
1.1 The closure can be used in duct, buried, overhead..etc
1.2 High quality impact material.pp and internal is PP,ABS
1.3 Designed for ftth with adapter if need.
1.4 Fiber storage with big basket
1.5 Modular fiber management system
1.6 Cable diameter range: 8~20 mm
1.7 Sealing way of cables:Mechanical seaing by silicon rubber
1.8 IP rating is IP68
Item | FOSC-001 | FOSC-002 | FOSC-003 | FOSC-004 | |||
Size(H*W*D)mm | 460*20*110 | 415*200*105 | 300*200*93 | 386*250*120 | |||
Cable port | 4 | 8 | 2 | 6 | |||
Max splice capacity | 120 | 144 | 72 | 192 | |||
Weight (KG) | 2.6 | 3.5 | 1.45 | 3.3 | |||
Type | Horizontal |
Item | FOSC-005 | FOSC-006 | FOSC-007 | FOSC-008 | FOSC-009 | FOSC-010 | |||||
Size(H*W*D)mm | 438*205 | 330*85 | 435*220 | 430*130 | 600*135 | 600*250 | |||||
Cable port | 4 | 3 | 3 | 5 | 5 | 5 | |||||
Max splice capacity | 288 | 36 | 240 | 96 | 96 | 576 | |||||
Weight (KG) | 2.8 | 1 | 3.1 | 3.5 | 3.6 | 5.5 | |||||
Material | ABS ,PC or PP | ||||||||||
Duration | 25 years | ||||||||||
Type | Vertical (Dome) |
Shenzhen DYS Fiber Optic Technology is a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter. DYS win the honorary title of National High-tech enterprise by Shenzhen government in 2014.
With years of experiences in the fiber optic industry, our factory is fully equipped over 3500 square meters and more than 23 non dust production lines .About 200 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 8 production lines for standard jumper and 8 PLC Splitter production lines.
The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on.
All of our optical products are RoHS compliant and DYS also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, DYS fiber optic is looking forward to cooperate with you.
INNOVATIVE TECHNOLOGY
We always learn new technology by investing in production facilities, engineering process control systems, and talent development to maintain our status as a leading fiber optic connection solutions.
Sample
Within 1-2 working days
Wholesale orders
3-7 working days according various quantities
1. How many staff's we have?
Answer: About 200 well-trained staff and engineers.
2. When our company be established?
Answer: We started from year 2008.
3. What's our main products?
Answer: DYS dedicates to the developing, production, marketing of the Fiber Optic Cable,
Indoor/Outdoor Patch Cord, Splitter, Adapter, Attenuator, and so on.
4. What is the area of the factory?
Over 3500 square meters
More than 18 non dust productions lines in total
4 production lines for Fiber Optic Cable
2 high standard MPO/MTP Jumper assembly lines
8 production lines for standard Jumpe
4 PLC Pplitter production lines
5. What certificate we have?
Answer: ISO 9001: 2015, RoSH, CE, High and New Tech Enterprise Certficate.
