40CH 100GHz Flat-top Athermal AWG DWDM MUX DEMUX Module
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
DWDM Mux/Demux Athermal AWG Module 40 Channel AWG
-
Flat top/Gaussian Filter 40 Channel AAWG Module 40 CH 100GHz Athermal AWG Module
-
Mini Box 8Ch CWDM Passive Mux Demux Module, 1270~1610nm Compact CWDM 8+1CH CCWDM With 1310nm Upgrade Port
-
4CH 8CH 16CH 100GHz DWDM Module 8 Channel 16 Channel Mux Demux DWDM
-
8 16 18 channel WDM CWDM DWDM Mux Demux Module, 4CH fwdm cwdm mux 1310/1490/1550 FWDM cwdm mux demux
-
High density 8 channel 100G DWDM MUX DEMUX module for 5G data center application
Product Description
Product Description
DWDM Mux/Demux Athermal AWG Module 40 Channel AWG
DYS rack-mounted 40-channel DWDM multiplexer (Mux) and Demultiplexer (DeMux) chassis provide excellent solution for infrastructure savings by aggregating 40 different wavelengths onto a single fiber. These 1U products are protocol transparent. All 40 channels are in the C-band with spacing of 100 GHz between channels using high quality AWG Gaussian technology.
APPLICATION
DWDM Metro and Long Haul Networks
Fiber savings for Data Centers connectivity
FEATURES
High isolation
Low insertion loss
Dual power supply
Can be management by console and NMS
Expoxy-free optical path
Low total integrated crosstalk
Excellent stability & reliability
Excellent wavelength accuracy & stability
Athermal design
Parameter | Value |
Number of Channels | 40 |
Channel Spacing | 100Ghz |
Operating Wavelength | C-band |
Passband Frequency | ±0.1nm |
Wavelength Accuracy | ±50pm |
Insertion Loss | <6.0dB |
Consistency of Insertion Loss | <1.2dB |
Insertion Loss Flatness | <0.5dB |
0.5dB Passband | >0.2nm |
1dB Passband | >0.4nm |
3dB Passband | >0.6nm |
20dB Passband | <1.2nm |
Adjacent Channel Isolation | ≥25dB |
Non-Adjacent Channel Isolation | ≥30dB |
Total Crosstalk | 22 dB |
Return Loss | ≥40dB |
Polarization Dependent Loss | <0.5ps |
Polarization Mode Dispersion | <0.5ps |
Maximum Load Optical Power | 24dBm |
Monitoring Range of Optical Power | -35dBm ~ +23dBm |
Connector Form | LC/UPC |
Operating Temperature | -10~+65℃ |
Relative Humidity | 95% |
Dimensions | 19-inch 1U rack (440 x 220 x 44mm) |
