2~24 Core Super Mini UniTube Air Blown Fiber Optic Cable
- 1000 per Month
- T/T Credit Card
- Double jacket Direct buried GYTA53 type Outdoor Fiber Optic Cable
- Factory Price Outdoor Self-supporting Aerial fibra optica adss 12 core 24 core span 100m adss fiber optic cable
- 2 / 4 / 6 / 8 / 12 / 16 / 24 Core Single Mode Outdoor Armoured G657A GYXTW Fiber Optical Cable
- Factory Price Outdoor fiber optic wire adss 12 core 24 core fibre optique fiber optical G652D cable roll drum
- Fiber Optic Isolator EDFA/CATV Used Wide Band High Isolation 3 Ports 1x2 40 0.35 Db ( Max 0.5 ) 1310 or 1550 Nm 0.10 Db CN;GUA
- 1x2 1310 1490 1550nm optical receiver epon edfa filter cwdm
Product Description
DYS's Air Blown Mini Cable (MINI) is small size, light weight, enhanced surface outer sheath fiber unit designed for blowing into micro tube bundles by air flow. The outer thermoplastic layer provides a high level of protection and excellent installation properties. It is usually applied in FTTX.
APPLICATION
Long-distance communication,LAN Used for air-blown laying in micro-tube FTTX system
FEATURES
Small diameter Frees up capital to expand network and client base Network design flexibility 5/3.5mm microduct suitable Easy to upgrade Greater blowing distance Fiber: G.G652D, G.657A1, G.657A2 & multimode fiber
P/N | Fiber count(F) | Nominal diameter(mm) | Nominal weight(kg/km) | Min. bend radius(mm) | Temperature(℃) |
MINI-2G652D-PE | 2 | 2.0±0.1 | 4 | 20 times ofcable diameter | -30 to +50 |
MINI-4G652D-PE | 4 | 2.0±0.1 | 4 | ||
MINI-6G652D-PE | 6 | 2.3±0.1 | 5 | ||
MINI-8G652D-PE | 8 | 2.3±0.1 | 5 | ||
MINI-12G652D-PE | 12 | 2.3±0.1 | 5 | ||
MINI-24G652D-PE | 24 | 2.3±0.1 | 7.5 |
Shenzhen DYS Fiber Optic Technology is a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter. DYS win the honorary title of National High-tech enterprise by Shenzhen government in 2014.
With years of experiences in the fiber optic industry, our factory is fully equipped over 3500 square meters and more than 23 non dust production lines .About 200 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 8 production lines for standard jumper and 8 PLC Splitter production lines.
The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on.
All of our optical products are RoHS compliant and DYS also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, DYS fiber optic is looking forward to cooperate with you.
