Fiber Media Converter 10/100M 3 Fiber Port +2 RJ45 Port 3PO and 2 LAN Port
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2014
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Gigabit SFP Media Converter With 1000M 8 SFP Fiber Port 1 RJ45 Ethernet PortNegotiableMOQ: 1 -
Power Supply for 14 16 Port Media Converter Chassis Rack 5 V 12 A High QualityNegotiableMOQ: 1
-
FTTH ODB FDB 8 Core Fiber Optic Distribution Terminal Box NapNegotiableMOQ: 1
-
Fiber Media Converter 10/100M 1Fiber Port +2 RJ45 Port 1PO and 2 LAN PortNegotiableMOQ: 1
-
10/100M Single Mode 3Fiber +2RJ45 Ethernet Media Converter High QualityNegotiableMOQ: 1
Related Products
Product Description
Product Description :
The 10/100 Mbps adaptive fast Ethernet fiber transceiver (also called photoelectric medium converter), built-in eight ports 10M/100Mbps adaptive switch, can convert eight independent 10 Base-T and 100 Base-TX twisted pair electrical signals to 100 optical signals. which extends the network transmission distance from the limit of 100 m of copper wire to 20 Km( single mode full duplex mode). Support two different network connection media types :10/100 Base-TX and 100 Base-FX, to realize data transmission between two network connection media by using switching technology and storage and forwarding technology. Support double fiber single mode and single fiber single mode multi-fiber transmission.
Product Details:
◆ provide eight independent 10 M/100Mbps adaptive switching twisted-pair ports for backup and multi-user access
The 10/100 Mbps adaptive fast Ethernet fiber transceiver (also called photoelectric medium converter), built-in eight ports 10M/100Mbps adaptive switch, can convert eight independent 10 Base-T and 100 Base-TX twisted pair electrical signals to 100 optical signals. which extends the network transmission distance from the limit of 100 m of copper wire to 20 Km( single mode full duplex mode). Support two different network connection media types :10/100 Base-TX and 100 Base-FX, to realize data transmission between two network connection media by using switching technology and storage and forwarding technology. Support double fiber single mode and single fiber single mode multi-fiber transmission.
Product Details:
◆ provide eight independent 10 M/100Mbps adaptive switching twisted-pair ports for backup and multi-user access
◆ adopts 1310/1550 nm or 1310/1550 nmDFB single fiber optoelectronic integration module, the performance is stable and reliable.
◆ single fiber optic transceiver must be used in pairs, That is ,1310 nm transmitting ,1550 nm receiving and 1550 nm transmitting ,1310 nm receiving pairing using a single fiber transceiver using one fiber to achieve two-way data transmission, Same function as double fiber, But it saves one fiber
◆ uses a unique switch chip design, With 1 M SSRAM buffer ,2 K MAC address table
◆ broadcast filtering function, address automatic learning and automatic update function and storage and forwarding operation mechanism
◆ Ethernet 10 or 100 fiber-optic medium converter support IEEE 802.3、IEEE 802.3U 、IEEE 802.3X 、IEEE 802.1d
◆ support full duplex flow control or half duplex backpressure flow control work, With automatic negotiation (Auto Negotiation) capability
◆ support 10 Mbps and 100 automatic adaptation (full dual working bandwidth up to 200 Mbps) to provide good optical and electrical characteristics of high quality optoelectronic integrated modules, Ensure reliable data transmission, Long working life
◆ provision of remote link loss diagnosis, port link connection diagnosis, dynamic data transmission, full/half duplex, rate
indicator
◆ dual RJ-45 port NIC and HUB, The NIC connection computer network card or HUB connection switch, hub
◆ external high precision power supply, small housing design appearance unique, internal power consumption :2.5 w (input: AC140~260 V), the average failure-free working time is more than 50,000 hours, Comply with telecom-level operating standards
◆ complete after-sales service, Provision of three years of quality assurance and life-long maintenance services
◆ broadcast filtering function, address automatic learning and automatic update function and storage and forwarding operation mechanism
◆ Ethernet 10 or 100 fiber-optic medium converter support IEEE 802.3、IEEE 802.3U 、IEEE 802.3X 、IEEE 802.1d
◆ support full duplex flow control or half duplex backpressure flow control work, With automatic negotiation (Auto Negotiation) capability
◆ support 10 Mbps and 100 automatic adaptation (full dual working bandwidth up to 200 Mbps) to provide good optical and electrical characteristics of high quality optoelectronic integrated modules, Ensure reliable data transmission, Long working life
◆ provision of remote link loss diagnosis, port link connection diagnosis, dynamic data transmission, full/half duplex, rate
indicator
◆ dual RJ-45 port NIC and HUB, The NIC connection computer network card or HUB connection switch, hub
◆ external high precision power supply, small housing design appearance unique, internal power consumption :2.5 w (input: AC140~260 V), the average failure-free working time is more than 50,000 hours, Comply with telecom-level operating standards
◆ complete after-sales service, Provision of three years of quality assurance and life-long maintenance services
Size |
161*94*26mm |
Transmission rate |
100Mbps |
Fiber type |
Single mode single fiber |
shell material |
Frosted metal |
Interface Type |
SC |
Support |
1 transceiver, 1 power , 1 manual |
