Product Pictures:
Features:
1. sfp module
2.Dual data-rate of 1.25Gbps/1.063Gbps operation
3.1310nm FP laser and PIN photodetector for 2-20km transmission
4.Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
5.Digital Diagnostic Monitoring: Internal Calibrationor External Calibration
6.Compatible with SONET OC-24-LR-1
7.Compatible with RoHS
General Description:
1.The sfp 1.25g module are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 2km 10KM transmission distance with SMF.
2.The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
3.The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
Applications:
- Gigabit Ethernet
- Fiber Channel
- Switch to Switch interface
- Switched backplane applications
- Router/Server interface
- Other optical transmission systems
Ordering Information:
More to list...
Compatible Brand:
More Products:
Certifications:
Our Company:
Rollball Comm-tech, established in 2000,located in Shenzhen China,specializes in providing high-performance fiber optic communication products and accessories for telecommunication, broadcast, CATV and network industries worldwide for 8 years.
Supplying fiber patch cord, pigtail ,fiber optic splitter,Transceiver,POE switch,Media converter, Fiber optics,OADM and CWDM DWDM MUX/DEMUX etc.
At Rollball, we believe that quality is essential to the company's success. As a result, we strictly monitor our ISO 9001:2000-certified production processes. Also, we inspect every aspect of production, from raw material examination to final inspections and shipping.
