Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > 1x16 SC UPC Mini Mode SM With SC Connector Mini-module Pemisah Serat PLC Splitter Mini Type Plc Splitter 1x16
1x16 SC UPC Mini Mode SM With SC Connector Mini-module Pemisah Serat PLC Splitter Mini Type Plc Splitter 1x16
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
1990
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1x16 SC APC Mini Mode SM With SC Connector Mini-module Pemisah Serat PLC Splitter 1x16 Mini PlcNegotiableMOQ: 1 -
1x32 SC APC Mini Mode SM With SC Connector Mini-module PLC Splitter sc Apc 1x32 Mini Plc SplitterNegotiableMOQ: 1
-
1x2 SC UPC ABS Box Single Mode Fiber Optic PLC Splitter Fiber Splitter ABS Box Module sc Upc 1x2 Abs Box Plc SplitterNegotiableMOQ: 1
-
1x2 SC APC ABS Box Single Mode Fiber Optic PLC Splitter Fasersplitter ABS Box Module 1x2 Plc sc SplitterNegotiableMOQ: 1
-
1x4 SC APC ABS Box Single Mode Fiber Optic PLC Splitter Pemisah Serat ABS Box Module 1x4 Abs Plc SplitterNegotiableMOQ: 1
Product Description
Parameter |
Unit |
1×2 |
1×4 |
1×8 |
1×16 |
1×32 |
1×64 |
|||||||||||
Fiber Type |
/ |
G.657A, or customized |
||||||||||||||||
Operating Wavelength |
nm |
1260~1650 |
||||||||||||||||
Insertion Loss |
P |
Max |
dB |
4.0 |
7.0 |
10.4 |
13.5 |
16.8 |
20.5 |
|||||||||
S |
Max |
dB |
4.2 |
7.3 |
10.6 |
13.8 |
17.1 |
20.8 |
||||||||||
PDL |
Max |
dB |
0.2 |
0.3 |
0.3 |
0.3 |
0.3 |
0.5 |
||||||||||
Loss Uniformity |
Max |
dB |
0.6 |
0.8 |
1.0 |
1.4 |
1.6 |
2.0 |
||||||||||
Return Loss |
Min |
dB |
55(P Grade)/50(S Grade) |
|||||||||||||||
Directivity |
Min |
dB |
55 |
|||||||||||||||
Operating Temperature |
℃ |
-40 ~ +85 |
||||||||||||||||
Storage Temperature |
℃ |
-40 ~ +85 |
||||||||||||||||
Dimension(L×W×H) |
mm |
40×4×4 |
50×7×4 |
60×12×4 |
||||||||||||||
Remark: The above parameters do not include connectors; If connectors are added, the insertion loss will increase 0.2dB each. |
||||||||||||||||||
Parameter |
Unit |
2×2 |
2×4 |
2×8 |
2×16 |
2×32 |
2×64 |
|||||||||||
Fiber Type |
/ |
G.657A, or customized |
||||||||||||||||
Operating Wavelength |
nm |
1260~1650 |
||||||||||||||||
Insertion Loss |
P |
Max |
dB |
4.0 |
7.3 |
10.6 |
13.9 |
17.2 |
20.8 |
|||||||||
S |
Max |
dB |
4.2 |
7.5 |
11.0 |
14.5 |
17.5 |
21.0 |
||||||||||
PDL |
Max |
dB |
0.2 |
0.3 |
0.3 |
0.3 |
0.3 |
0.5 |
||||||||||
Loss Uniformity |
Max |
dB |
0.8 |
1.0 |
1.2 |
1.5 |
1.8 |
2.0 |
||||||||||
Return Loss |
Min |
dB |
55(P Grade)/50(S Grade) |
|||||||||||||||
Directivity |
Min |
dB |
55 |
|||||||||||||||
Operating Temperature |
℃ |
-40 ~ +85 |
||||||||||||||||
Storage Temperature |
℃ |
-40 ~ +85 |
||||||||||||||||
Dimension(L×W×H) |
mm |
40×4×4 |
50×7×4 |
60×12×4 |
||||||||||||||
Remark: The above parameters do not include connectors; If connectors are added, the insertion loss will increase 0.2dB each. |
||||||||||||||||||
Related Products
Application Scenarios
Packing&Shipping
1, mini type plc splitter 1x16 is packed in PE bag/carton box, and the test result stick in the package bag,
2, certain pcs mini type plc splitter 1x16 packed in a standard paper carton, carton size is 40*40*40cm,
3, the paper cartons could packed 27 or 36 cartons per pallets.
4, shipment are available from FedEX, DHL, UPS, TNT, etc. international express to airfreight and seafreight.
3, the paper cartons could packed 27 or 36 cartons per pallets.
4, shipment are available from FedEX, DHL, UPS, TNT, etc. international express to airfreight and seafreight.
Exhibition
our services
1.Advanced production and testing equipment
2.Professional manufacturer, 100% tested.
3.Full compliance with ISO 9001:2008 quality management system
4.Our company has experienced professional team
5.Provide reliable solutions and satisfactory services
6.Warmly services with careful attentions.
7.Can provide your specific inquiry within 24 hours. Advanced production and testing equipment
Company Introduction
Our company has rich experienced professional team and is committed to providing customers with reliable solution and satisfactory services. Through continuous development and expansion of our company, we now have customer around the world, especially in North America, South America, Europe, and Asia. Our products and services have been well received by customers. In the future, we will continue to provide customers with safe and reliable FTTX solutions.
WeUnion Communication Technology Co., Ltd. is a professional manufacturer focuses on development, production, and sales of fiber telecommunication product. We provide Fiber Optic Cable, Fiber Patch cord, fiber pigtail, Optic PLC splitter, Fiber Distribution Boxes and relevant products which are widely used in FTTX, LAN, WAN, G-Pon, E-Pon Project. Our company has advance production and test equipments, strict production and quality control system, and stable supply chain. We are fully compliant with ISO9001: 2008 quality management system, we guarantee that our products are IEC60794 and Telcordia-GR-326-Core standard compliant, also compliant with our customers' varied requirements.
FAQ
Q1: When can I get the quotation back?
A:Generally, quotes will be replied within 24 hours or faster(weekends not included), however, a few of days would be taken for special ones.
Q2:How about the cable's quality ?
A: Our factory has dug in this industry for many years and sold to many countries in the world. We are fully compliant with ISO9001: 2008 quality management system, we guarantee that our products are IEC60794 and Telcordia-GR-326-Core standard compliant. We have a series of professional equipment and manufacturing instruments to make sure reliable quality of our products.
Q3: How do l assure that you are a reliable supplier?
A: We are the Assessed Supplier of . Alibaba as the third party to verify our factory and office to confirm we are a real and reliable supplier. If you are willing to verify that through the phone or video, you are welcome at any time.
Q4: Could the OEM be accepted and what's the MOQ?
A: Of course, your customization order is always welcomed. The MOQ Depends on different items, each item has its own minimum quantity. Your satisfaction is our maximum motivation.
