DC-DC Single Phase Solid State Relay DD Output 5-220VDC Input 5-32VDC SSR Relay Industrial Solid State Relay Module
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2009
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Single Phase Solid State Relay SSR-40DA SSR-25DA SSR-10DA DC to AC 3-32VDC Input 24-380VAC Output Solid State Relay ModuleNegotiableMOQ: 1 -
Start Relay RL180 120A 12V 24V Power Automotive Heavy High Current Starting Relay Car Switch Truck Motor RelayNegotiableMOQ: 1
-
Solid State Relay Module SSR-25AA SSR-40AA SSR 40A 80-250VAC Input to 24-380VAC Output Industry ControlNegotiableMOQ: 1
-
Automobile Relay Waterproof Integrated Wired DC12V 40A 5Pin 4pin Auto Relay With 105mm Length Wires Car RelayNegotiableMOQ: 1
-
AH3-3 Time Relay AC220V Delay Timer Time Relay 8Pin 1S 10S 30S 60S Power On Delay Timer Time Relay With PF083A SocketNegotiableMOQ: 1
Parameters
Solid state relay (SSR) abbreviations electronic non-contact switch, the main characteristics of tiny control input signal, the direct drive high current load. Product is used widely, advantages: long life, non-contact, no spark, no noise, no electromagnetic interference, fast switching speed, strong anti-interference ability, reliable operation, and small size, resistant to vibration, explosion-proof, anti-corrosion, can compatible with TTL, DTL, HTL integrated circuit.
Insufficient at present is mainly the output contact not like contactor which yao, only one group; Over 40 a additional load due to the pressure drop, temperature rise quickly, it is important to note that the cooling, you also can choose special solid heat dissipation
Specification:
| Type | DC-DC SSR |
| Load Current | 40A |
| Load Voltage | 5-220VAC |
| Control Voltage | 3-32VDC |
| Control Current | DC3-25mA |
| On voltage | ≤1.5V |
| Off Leakage Current | ≤2mA |
| On-off Time | ≤10ms |
| Dielectric Strength | 2500VAC |
| Insulation Resistance | 1000M/500VDC |
| Ambient Temperature | -30~+75 |
| Mounting Methods | Bolting |
| The work instructions | LED |
Remark: When you place an order, please note that you need 10A, 25A or 40A !!!
Product display
