PM9804 0.5 Class AC/DC Digital Power Meter

PM9804 0.5 Class AC/DC Digital Power Meter photo-1
PM9804 0.5 Class AC/DC Digital Power Meter photo-2
PM9804 0.5 Class AC/DC Digital Power Meter photo-3
PM9804 0.5 Class AC/DC Digital Power Meter photo-4
PM9804 0.5 Class AC/DC Digital Power Meter photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

PM9804 0.5 class AC/DC digital power meter

Products Features:

LED digital screen display: voltage, current, power, power factor/frequency

All measurements are Trms

Not affected by external noise

Support data locking

switch Range

Areas of Application

Power consumption test for household appliance

Power consumption test for the air-condition

Power consumption test for LED light products

Power consumption test for electric machine and Motor

Power consumption test for chargers and switching power supply



Product Name

PM9804

Product Type

AC/DC Type

Measuring Items

Voltage V, Current A, Active power W, Power factor PF, Frequency Hz

Measuring Mode

Trms

Voltage Range

5V~600V AC/DC

Current Range

5mA~20A AC/DC

Power Range

0.1W-12kW(U*I*PF)

Power factor range

0.001-1.000

Frequency Range

45-65Hz

Basic Accuracy

±(0.4%Read+ 0.1%Range)

Data refresh Cycle

3tims/s

Input Impedance

2MΩ(All Voltage)

Power Supply

AC 100-240V 45-440Hz; DC 100-300V

Communication Interface

Optional RS232/485

AC/DC/RMS

AC/DC/RMS

AD Converter

The speed is 8K/S, 24 bits voltage and current simultaneous sampling

Weight

1.7KG

Dimension

W×H×D(225mm×112mm×355mm)(Without Package)



PM9804 0.5 class AC/DC digital power meterPM9804 0.5 class AC/DC digital power meterPM9804 0.5 class AC/DC digital power meterPM9804 0.5 class AC/DC digital power meterPM9804 0.5 class AC/DC digital power meter

PM9804 0.5 class AC/DC digital power meterPM9804 0.5 class AC/DC digital power meterPM9804 0.5 class AC/DC digital power meter
