Small Power mode digital power meter, CE certificate digital factor power meter
Products Features:
1. Four windows LED display, voltage, current, power, power factor/frequency at the same time
2. All measurements are TRMS
3. Automatic range
4. Accuracy: 0.5
5. Min. current: 0.5mA, Max current:2.2A
6. Not affected by external noise
7. Suitable for various electricity situation with 100-240V ac power supply
8. Its shell uses soft rubber material which is beautiful shatterproof and durable
9. Support data locking
10. Can be set to a lower limit alarm function
|
Single Phase |
|
|
Display |
LED Digital Screen |
|
Measuring items |
Voltage-V, current-A, active power-W, power factor-PF, frequency-Hz |
|
Voltage Range |
5V-600V AC(Switch the range automatically Peak Voltage:700V AC Min test voltage:5v(Below 5v, can be customized) |
|
Current Range |
0.5mA-2A AC(Switch the range automatically) Peak Current:2.6A AC Min. test current :0.5mA AC |
|
Power Range |
0.01W-1.2KW(Suitable for standby power test and small power electrical products testing) |
|
Power factor range |
0.001-1.000 Compute mode: Watt(W)/[Voltage(V)*current(A)]=Power factor(PF) |
|
The frequency range |
45-65Hz |
|
Communication Interface |
Optional RS232 or RS485, Relay output |
|
Basic Accuracy |
±(0.4% reading +0.1%range+1 digit) |
|
Measuring Speed |
Five times per second |
|
Input Impedance |
About 2MΩ(All voltage) |
|
Power supply |
100~250V AC, 45-400Hz, 100-300V DC |
|
Volume and weight |
355mm(L)*225mm(W)*112mm(H),Holesize:225mm(W)*99mm(H)≈1.7KG |
|
Attachment |
Power line, Operation Manual, warranty card |
Dispatch is arranged within 1-3days once your payment is finished verification by our Financial department. If there is no option of express you need. Pls contact us in advance.
The delivery time show when you choice the express is for reference. We don't guarantee the time the same with it all the time, due to difference in customs clearing times in individual countries, which may affect how quickly your product is inspected.
Dongguan NAPUI Electronic Technology Co., Ltd is 8 years specialist digital power meter Manufacturer in China.
All the power meter waranty are 12 months.
All the items are EXW.
