Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor

Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor thumbnail-1
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor thumbnail-2
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor thumbnail-3
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor thumbnail-4
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor thumbnail-5
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor photo-1
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor photo-2
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor photo-3
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor photo-4
Elecnova SFR-L Series Reactive Power Compensation Intelligent Low Voltage Super Power Capacitor photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2010
Annual Export Value:
Above US$100 Million
Contact Supplier Request Quote Chat Now
Jiangsu Sfere Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description

Elecnova SFR-L is designed for 0.4kV voltage distribution network. It is used as a new generation of compenstation module with functions of energy saving, reduction of line loss, power factor enhancement and improvement of power quality.

Product Name
Elecnova SFR-L series reactive power compensation intelligent low voltage super power capacitor
Type
Capacitor
Switching mode
Zone-crow switching
Standard
GB/T 15576-2008
Working temperature
-15C~45C
Altitude
less than 2000m
Thread
coarse, fine
Certification
CE,UL,MID
Technical Parameters
Function
Specification


Measurement accuracy
Current
≤1.0%(5%~120%In)
Voltage
≤0.5%(80%~120%Un)
Power
≤2%
Power factor
≤±0.01


Compensation operation
Working voltage
AC 380V±20%, distortion rate≤5%
Consumption
≤5VA
Max. working current
1.35*In
Switching inrush current
≤3*In


Host protection
Over voltage
430V(can be set)
Under voltage
300V(can be set)
Harmonic exceeding
0%~100%(can be set)


Local protection
Over current
0~100A(can be set)
Over temperature
55°C(can be set)
Unbalance
50%(can be set)
Production Process

                              SMT

                           AOI Test

                   Plug-In Mounting

                       Wave Soldering

                          Assembling

                            Inspection

Packing & Delivery



FAQ

Q: Are you trading company or manufacturer ?

A: We are factory located in Jiangyin City, Jiangsu Province.

Q: How long is your delivery time?

A: 7-10 working days for the production with stock.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we provide sample but it is not free.

Q: What is your terms of payment ?

A: Order amount less than $3000, 100% pail before delivery, order amount more than $3000%, 30% as deposite, 70% before delivery.
