Factory Price Small Laboratory Filter Bag Centrifuge Machine
US$ 2000 - 3000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HEMHO
Place of Origin:
China
Model Number:
YGT450
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
30 days
Related Products
-
Small Horizontal Laboratory Decanter Centrifuge With Factory PriceUS$ 20000 - 25000MOQ: 1 Set -
Automatic Horizontal Salt Separation Centrifuge MachineUS$ 23000 - 25000MOQ: 1 Set
-
230V 0.92A 210W 2600RPM For Ebmpapst R2E225RA92-48 Centrifugal FanNegotiableMOQ: 1 Piece
-
Centrifugal Separator Centrifuge MilkNegotiableMOQ: 1
-
Centrifugal BlowerUS$ 1000 - 20000MOQ: 1 Set
Brand Name
HEMHO
Place of Origin
China
Model Number
YGT450
Type
Separating Plant
Certification
CE, ISO9001
After-sales Service Provided
No overseas service provided
Warranty
1 year
Weight
300kg
Dimension(L*W*H)
1000mm×700mm×1100mm
Condition
New
Product Type
Other
Voltage
380v or customized
Power(W)
1.5kw
Hemho mini Laboratory centrifuge designs YGD series centrifuge following the experimental requirements of GMP and various enterprises and institutions. It has the characteristics of compact structure, exquisite appearance, high speed, low noise, stable operation, and no basic installation. The YGD series is a closed structure. The machine adopts a flat large open cover structure. There are feeding pipes, washing pipes, sight glasses, etc., on the flip cover, which can realize online feeding (if there is a reactor, it can be directly connected to the centrifuge), and the machine runs more Stable and more beautiful. It is suitable for the environment where the material smell is strong, and the operation needs to be closed. The whole machine is stainless steel.
Application
YGD series belongs to centrifugal filtration separation, suitable for the separation of most granular materials.
It is widely used in small and medium-sized material tests in colleges, universities, scientific research units, pharmaceutical, chemical, food, fine chemical and other enterprises and institutions.
Working Principle
YGD consists of the casing, drum, base, transmission and other components. The drum operation is driven by the motor wheel through the triangular belt to drive the passive wheel for operation. For medium with high solid content, feeding is first followed by starting, while medium with high liquid content is first started followed by feeding (on-line feeding and washing functions can be realized). The material is uniformly fitted to the drum wall through the centrifugal field. The liquid phase is discharged through the filter screen through the drum filter hole, and the solid phase is kept in the drum for a long time. When the separation requirements are met, the power supply is cut off (energy consumption braking or braking device makes the drum stop), and the material is automatically stopped and discharged from the upper part manually.
