Csbattery 12V70ah Bateria Inverter Rechargeable Gel Battery for Power-Bank/Power-System/Energy-Storage/Ada

Csbattery 12V70ah Bateria Inverter Rechargeable Gel Battery for Power-Bank/Power-System/Energy-Storage/Ada photo-1
Csbattery 12V70ah Bateria Inverter Rechargeable Gel Battery for Power-Bank/Power-System/Energy-Storage/Ada photo-2
Csbattery 12V70ah Bateria Inverter Rechargeable Gel Battery for Power-Bank/Power-System/Energy-Storage/Ada photo-3
Csbattery 12V70ah Bateria Inverter Rechargeable Gel Battery for Power-Bank/Power-System/Energy-Storage/Ada photo-4
Csbattery 12V70ah Bateria Inverter Rechargeable Gel Battery for Power-Bank/Power-System/Energy-Storage/Ada photo-5
US$ 59.42 - 65.19 MOQ: 24 Pieces
Key Specifications
Get Latest Price
Brand Name:
CSBattery
Place of Origin:
China
Model Number:
GB12-70G
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
7 days
Brand Name CSBattery
Place of Origin China
Model Number GB12-70G
Type Other, lead - acid battery
Size Other, 350*167*178*178mm
Nominal Capacity 70Ah
Nominal Voltage Other, 12v

CSBattery Deep Cycle GEL 12V Battery GB series


--------------------------------------------------------------
CSBattery Deep Cycle GEL12V Battery GB12-70sepcification

GB12G-70
Nominal Voltage  12V (6 cells per unit)
Design Floating Life @ 25ºC  12 Years
Nominal Capacity @ 25ºC  10 hour rate@7.0A,10.8V 70Ah
Capacity @ 25ºC 20 hour rate (3.89A, 10.8V)  77.8Ah
5 hour rate (12.8A, 10.5V)  64Ah
1 hour rate (46.6A,9.6V)  46.6Ah
Internal Resistance  Full Charged Battery@ 25ºC  ≤7.0mΩ
Ambient Temperature Discharge  -20ºC~60ºC
Charge  -10ºC~60ºC
Storage  -20ºC~60ºC
Max.Discharge Current @ 25ºC 420A(5s)
Capacity affected by Temperature (10 hour ) 40ºC  105%
25ºC  100%
0ºC  85%
-15ºC 65%
Self-Discharge@25ºCper Month  3%
Charge (Constant Voltage) @ 25ºC Standby Use  Initial Charging Current Less than 17.5A Voltage 13.6-13.8V
Cycle Use Initial Charging Current Less than 17.5A Voltage 14.4-14.9V
Dimension (mm*mm*mm) Length 350±1 * Width 167±1 * Height  178±1 (Total Height 178±1)
Weight (kg)  22.0±3%

CSBattery Factory


CSBattery ENERGY CO.,LIMITED is a professional manufacturer and exporter of environmental friendly Rechargeable
Deep Cycle AGM Sealed Lead Acid (SLA) Batteries, Solar GEL Batteries, Front Terminal Battery, High Temperature long life
GEL battery, OPzV Battery, Car/Auto Batteries, Telecom Batteries, Lithium batteries and other Solar related products such as

Solar inverter, Solar charger controller, Solar panel and so on.


Product specifications and models
-----------------------------------------------------

12V  SEALED FREE MAINTENANCE GEL BATTERY
Model Nominal Voltage (V) Capacity (Ah)  Dimension (mm) Net Weight Gross Weight Terminal
Length Width Height Total Height kgs kgs
GB12-33G 12 33/10HR 196 130 155 167 10.2 10.5 M6
GB12-38G 12 38/10HR 198 166 172 172 12.5 12.8 M6
GB12-45G 12 45/10HR 198 166 174 174 13.2 13.5 M6
GB12-50G 12 50/10HR 229 138 208 212 15.7 16.2 M6
GB12-55G 12 55/10HR 229 138 208 212 16.4 16.9 M6
GB12-65G 12 65/10HR 350 167 178 178 20.8 21.3 M6
GB12-70G 12 70/10HR 350 167 178 178 21.8 22.3 M6
GB12-75G 12 75/10HR 260 169 211 215 22.3 22.8 M6
GB12-80G 12 80/10HR 260 169 211 215 23.8 24.3 M6
GB12-85AG 12 85/10HR 331 174 214 219 25.3 25.8 M6
GB12-90G 12 90/10HR 307 169 211 216 27 27.5 M6
GB12-100GC 12 100/20HR 307 169 211 216 27.5 28 M6
GB12-100GB 12 100/10HR 331 174 214 219 28.5 29 M8
GB12-100GA 12 100/10HR 331 174 214 219 29.5 30 M8
GB12-120G 12 120/20HR 407 173 210 233 33.5 34 M8
GB12-120GA 12 120/10HR 407 173 210 233 34.5 35 M8
GB12-135G 12 135/10HR 341 173 283 288 41.5 42 M8
GB12-150GB 12 150/20HR 484 171 241 241 41.5 42 M8
GB12-150GA 12 150/10HR 484 171 241 241 44.5 45 M8
GB12-160G 12 160/10HR 532 206 216 222 49 49.5 M8
GB12-180G 12 180/10HR 532 206 216 222 53.5 54 M8
GB12-200GB 12 200/20HR 522 240 219 225 56.5 57 M8
GB12-200GA 12 200/10HR 522 240 219 225 58.7 59.2 M8
GB12-230G 12 230/10HR 522 240 219 225 61.5 62 M8
GB12-250G 12 250/10HR 520 268 220 225 70.5 71 M8
GB12-300G 12 300/10HR 520 268 220 226 77.5 78 M8






Product Tags: solar battery , gel battery , lead acid battery , 12v battery , ups battery
