Home > Electrical & Electronics > Battery, Storage Battery & Charger > Storage Battery > Csbattery 12V200ah SLA Solar Power Gel Battery for Pump/Golf-Cart/Electrical-Tools
Csbattery 12V200ah SLA Solar Power Gel Battery for Pump/Golf-Cart/Electrical-Tools
US$ 155.24 - 162.23
MOQ: 12 Pieces
Key Specifications
Get Latest Price
Brand Name:
CSBattery
Place of Origin:
China
Model Number:
GB12-200
Payment & Shipping
Payment Methods:
Port of Shipment:
Shengzhen
Delivery Detail:
7 days
Related Products
-
Csbattery 2V600ah Solar Storage Tubular Opzv Gel Battery for Security System/Telecom/Electric UtilitiesUS$ 161.01 - 168.26MOQ: 50 Pieces -
Csbattery 6V420ah Energy Storage Gel Solar Battery for Wind-Power-Storage/Solar-Street-Lights/LampUS$ 178.55 - 186.58MOQ: 12 Pieces
-
Csbattery 2V800ah Solar Storage Tubular Opzv Gel Battery for Security System/Telecom/Electric UtilitiesUS$ 204.98 - 214.31MOQ: 50 Pieces
-
Csbattery 2V1200ah Solar Storage Tubular Opzv Gel Battery for Security System/Telecom/Electric UtilitiesUS$ 293.63 - 305.57MOQ: 50 Pieces
-
Csbattery 2V1000ah Solar Storage Tubular Opzv Gel Battery for Security System/Telecom/Electric UtilitiesUS$ 247.03 - 257.07MOQ: 50 Pieces
Brand Name
CSBattery
Place of Origin
China
Model Number
GB12-200
Type
Other, lead Acid
Size
Other, 522*240*219*224
Nominal Capacity
12V200Ah
Nominal Voltage
12V
CSBattery Deep Cycle GEL 12V Battery GB12-200
-------------------------------------------------------------------------------------
CSBattery Deep Cycle GEL12V Battery GB12-200 sepcidication
| GB12G-200 | |||
| Nominal Voltage | 12V (6 cells per unit) | ||
| Design Floating Life @ 25ºC | 15 Years | ||
| Nominal Capacity @ 25ºC | 10 hour rate@20.0A,10.8V | 200Ah | |
| Capacity @ 25ºC | 20 hour rate (11.0A, 10.8V) | 220Ah | |
| 5 hour rate (35.4A, 10.5V) | 177Ah | ||
| 1 hour rate (132A,9.6V) | 132Ah | ||
| Internal Resistance | Full Charged Battery@ 25ºC | ≤2.5mΩ | |
| Ambient Temperature | Discharge | -20ºC~60ºC | |
| Charge | -10ºC~60ºC | ||
| Storage | -20ºC~60ºC | ||
| Max.Discharge Current | @ 25ºC 1200A(5s) | ||
| Capacity affected by Temperature (10 hour ) | 40ºC | 105% | |
| 25ºC | 100% | ||
| 0ºC | 85% | ||
| -15ºC | 65% | ||
| Self-Discharge@25ºCper Month | 3% | ||
| Charge (Constant Voltage) @ 25ºC | Standby Use | Initial Charging Current Less than 50A Voltage 13.6-13.8V | |
| Cycle Use | Initial Charging Current Less than 50A Voltage 14.4-14.9V | ||
| Dimension (mm*mm*mm) | Length 522±1 * Width 240±1 * Height 219±1 (Total Height 224±1) | ||
| Weight (kg) | 56.5±3% | ||
Applicationg for GB Durable AGM VRLA Battery:
ØElectric Powered Vehicles ØWheel Chairs ØBTS Stations ØMedical Equipment Ø Solar and Wind ØGolf Cars and Buggies ØPower Tools ØControl System ØUPS systems ØEmergency systems
CSBattery ENERGY CO.,LIMITED is a professional manufacturer and exporter of environmental friendly Rechargeable
Deep Cycle AGM Sealed Lead Acid (SLA) Batteries, Solar GEL Batteries, Front Terminal Battery, High Temperature long life
GEL battery, OPzV Battery, Car/Auto Batteries, Telecom Batteries, Lithium batteries and other Solar related products such as
Solar inverter, Solar charger controller, Solar panel and so on.
Product specifications and models
----------------------------------------------------------
ØElectric Powered Vehicles ØWheel Chairs ØBTS Stations ØMedical Equipment Ø Solar and Wind ØGolf Cars and Buggies ØPower Tools ØControl System ØUPS systems ØEmergency systems
CSBattery ENERGY CO.,LIMITED is a professional manufacturer and exporter of environmental friendly Rechargeable
Deep Cycle AGM Sealed Lead Acid (SLA) Batteries, Solar GEL Batteries, Front Terminal Battery, High Temperature long life
GEL battery, OPzV Battery, Car/Auto Batteries, Telecom Batteries, Lithium batteries and other Solar related products such as
Solar inverter, Solar charger controller, Solar panel and so on.
Product specifications and models
----------------------------------------------------------
| 12V SEALED FREE MAINTENANCE AGM BATTERY | |||||||||
| Model | Nominal Voltage (V) | Capacity (Ah) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | kgs | kgs | ||||
| GB12-15 | 12 | 15/10HR | 152 | 99 | 96 | 102 | 3.8 | 4 | F2 |
| GB12-18 | 12 | 18/20HR | 181 | 77 | 167 | 167 | 5.2 | 5.4 | L1 |
| GB12-20 | 12 | 20/20HR | 181 | 77 | 167 | 167 | 6 | 6.2 | L1 |
| GB12-24 | 12 | 24/10HR | 166 | 126 | 174 | 174 | 7.7 | 7.9 | M6 |
| GB12-26 | 12 | 26/10HR | 166 | 175 | 126 | 126 | 8.3 | 8.6 | M6 |
| GB12-33 | 12 | 33/10HR | 196 | 130 | 155 | 167 | 10 | 10.3 | M6 |
| GB12-38 | 12 | 38/10HR | 198 | 166 | 172 | 172 | 12.3 | 12.6 | M6 |
| GB12-45 | 12 | 45/10HR | 198 | 166 | 174 | 174 | 13 | 13.3 | M6 |
| GB12-50 | 12 | 50/10HR | 229 | 138 | 208 | 212 | 15.5 | 16 | M6 |
| GB12-55 | 12 | 55/10HR | 229 | 138 | 208 | 212 | 16.2 | 16.7 | M6 |
| GB12-65 | 12 | 65/10HR | 350 | 167 | 178 | 178 | 20.5 | 21 | M6 |
| GB12-70 | 12 | 70/10HR | 350 | 167 | 178 | 178 | 21.5 | 22 | M6 |
| GB12-75 | 12 | 75/10HR | 260 | 169 | 211 | 215 | 22 | 22.5 | M6 |
| GB12-80 | 12 | 80/10HR | 260 | 169 | 211 | 215 | 23.5 | 24 | M6 |
| GB12-85A | 12 | 85/10HR | 331 | 174 | 214 | 219 | 25 | 25.5 | M6 |
| GB12-90 | 12 | 90/10HR | 307 | 169 | 211 | 216 | 26.5 | 27 | M6 |
| GB12-100C | 12 | 100/20HR | 307 | 169 | 211 | 216 | 27 | 27.5 | M6 |
| GB12-100B | 12 | 100/10HR | 331 | 174 | 214 | 219 | 28 | 28.5 | M8 |
| GB12-100A | 12 | 100/10HR | 331 | 174 | 214 | 219 | 29 | 29.5 | M8 |
| GB12-120 | 12 | 120/20HR | 407 | 173 | 210 | 233 | 33 | 33.5 | M8 |
| GB12-120A | 12 | 120/10HR | 407 | 173 | 210 | 233 | 34 | 34.5 | M8 |
| GB12-135 | 12 | 135/10HR | 341 | 173 | 283 | 288 | 41 | 41.5 | M8 |
| GB12-150B | 12 | 150/20HR | 484 | 171 | 241 | 241 | 41 | 41.5 | M8 |
| GB12-150A | 12 | 150/10HR | 484 | 171 | 241 | 241 | 44 | 44.5 | M8 |
| GB12-160 | 12 | 160/10HR | 532 | 206 | 216 | 222 | 48.5 | 49 | M8 |
| GB12-180 | 12 | 180/10HR | 532 | 206 | 216 | 222 | 53 | 53.5 | M8 |
| GB12-200B | 12 | 200/20HR | 522 | 240 | 219 | 225 | 56 | 56.5 | M8 |
| GB12-200A | 12 | 200/10HR | 522 | 240 | 219 | 225 | 58.2 | 58.7 | M8 |
| GB12-230 | 12 | 230/10HR | 522 | 240 | 219 | 225 | 61 | 61.5 | M8 |
| GB12-250 | 12 | 250/10HR | 520 | 268 | 220 | 225 | 70 | 70.5 | M8 |
| GB12-300 | 12 | 300/10HR | 520 | 268 | 220 | 226 | 77 | 77.5 | M8 |
