HSR-1200 Thermal Conductivity Silicone Sheet

HSR-1200 Thermal Conductivity Silicone Sheet thumbnail-1
HSR-1200 Thermal Conductivity Silicone Sheet photo-1
US$ 0.1 - 0.2 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
Hothree
Place of Origin:
China
Model Number:
HSR-1200
Contact Supplier Request Quote Chat Now
Shenzhen Hothree Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
3 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Hothree
Place of Origin China
Model Number HSR-1200
Material Fiberglass
Type Insulation Sheet
Application High Temperature



    Features and Benefits

    • Thermal conductivity: 0.9W/m-K

    • Electrical insulation

    • Flame retardant

hothree HSR-1200 (Thermal Conductive Insulating Silicone Gasket) is a high performance insulator.

It combines special film with a filled silicone rubber.

The result is a product with excellent thermal performance.

hothree HSR-1200(Thermal Conductivity Silicone Sheet) is designed to replace ceramic insulators

such as beryllium oxide, boron nitride and alumina.


hothree HSR-1200 (Thermally Conductive Insulators) can be die-cut into various shapes,easy to operate.

The thermal conductivity can reach 0.9w/m-k and the standard hardness is 85 shoreA.

Thickness is 0.23mm and the standard specification is W300mm*L50m/roll

Produced by our own formula, we can customize the color, hardness and thickness according to the requirements.


hothree HSR-1200 (Thermal Conductive Silicone Gasket)  Applications

• Power supplies

• Automotive electronics

• Power semiconductors


Configurations Available

• Sheet form, die-cut parts and roll form

• With or without pressure sensitive adhesive


hothree HSR-1200 (Thermal Conductivity Silicone Sheet) can replace BERGQUIST SP400,Sil Pad 400,SIL PAD TSP 900

BERGQUIST SP800,SIL PAD 800,SIL PAD TSP 1600,LAIRD TGARD-K52,LAIRD TGARD 220


Product Tags: Thermal Conductive Insulating Silicone Gasket , Thermally Conductive Insulators , Thermal Conductivity Silicone Sheet
