3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing

3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing thumbnail-1
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing thumbnail-2
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing thumbnail-3
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing thumbnail-4
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing thumbnail-5
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing photo-1
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing photo-2
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing photo-3
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing photo-4
3.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic Casing photo-5
US$ 226 - 230 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
UWO
Place of Origin:
China
Model Number:
USP30R3-CP
Contact Supplier Request Quote Chat Now
Foshan Uwotec New Energy Co.,ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name UWO
Place of Origin China
Model Number USP30R3-CP
Certification CE, ROHS
After-sales Service Provided Overseas third-party support available
Warranty One year
Weight 20
Dimension(L*W*H) 416*387*433
Condition New
Voltage 220V
Structure Tube Heat Exchanger
Power(W) 3200
Maximum Working Pressure 4.5A
Liquid Flow Rate 2m³/h
Description


Swimming pool mini heat pump, heating only, side discharge. Injection molded plastic cabinet. Single ordinary body color(Grey/Black).
1. Injection molded anti-fire ABS plastic casing: Innovated, unique and graceful design, provides a more personzlied and fashionable solution for above ground pools, jacuzzis or spas.
2. Renewed internal strucure design: Vertical water inlet/outlet, added compressor discharge temp.sensor and protection, L-shaped evaporator ect., ensure much higher energy efficiency.
3. With WiFi control.

Specification


Model No. USP 30R3-CP 40R3-CP

50R3-CP
Performance condition: Air temperature : 27°C, Inlet / Outlet water temerature: 26°C / 28°C, Humidity 80%.
Heating capacity kW 3.2 4.14 5.23
Power consumption kW 0.56 0.73 0.83
C.O.P W/W 5.71 5.67 6.30
Performance condition: Air temperature : 15°C, Inlet / Outlet water temerature: 26°C / 28°C, Humidity 70%.
Heating capacity kW 2.32 2.82 3.72
Power consumption kW 0.53 0.65 0.87
C.O.P W/W 4.37 4.34 4.27

Compressor
Rotary type with R32 refrigerant,GMCC or the similar brand.
Voltage
220-240V/50Hz/1PH
Rated current A 3.1 3.2 5.1
Advised pool volume(covered) m³ 5~15 8~18 10~22
Water side heat exchanger
Spiral round titanium tube in PVC shell
Water connection mm 32 or 38
Noise level(1m) dB(A) 46 47 48
Net weight kg 20 21 24
Gross weight kg 23 24 26
Net Dimension(WxDxH) mm 416*387*433
Packing Dimension(WxDxH) mm 480*420*480











Product Tags: heat pump for swimming pool , pool heater , heat pump
