3kw Mini Pool Heater, Air Source Heat Pump, Injection Molded Plastic Casing
US$ 226 - 230
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
UWO
Place of Origin:
China
Model Number:
USP30R3-CP
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan
Delivery Detail:
15 days
Related Products
-
16kW Full Inverter Pool Heat Pump, Swimming Pool Heater, Galvanized Steel CabinetUS$ 660 - 670MOQ: 1 Set -
4.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic CasingUS$ 247 - 252MOQ: 1 Set
-
5.0kw Mini Air Source Heat Pump, Pool Heater, Injection Molded Plastic CasingUS$ 268 - 272MOQ: 1 Set
-
18.0kw, Full Inverter Pool Heat Pump, Swimming Pool Heater, With Galvanized Steel CabinetUS$ 740 - 750MOQ: 1 Set
-
21.0kw, Swimming Pool Heat Pump, Pool Heater, Galvanized Steel Cabinet, Top DischargeUS$ 1290 - 1300MOQ: 1 Set
Brand Name
UWO
Place of Origin
China
Model Number
USP30R3-CP
Certification
CE, ROHS
After-sales Service Provided
No overseas service provided
Warranty
One year
Weight
21
Dimension(L*W*H)
416*387*433
Condition
New
Voltage
220V
Structure
Tube Heat Exchanger
Power(W)
3200
Maximum Working Pressure
7.2A
Liquid Flow Rate
3m³/h
Description
Swimming pool mini heat pump, heating only, side discharge. Injection molded plastic cabinet. Single ordinary body color(Grey/Black).
1. Injection molded anti-fire ABS plastic casing: Innovated, unique and graceful design, provides a more personzlied and fashionable solution for above ground pools, jacuzzis or spas.
2. Renewed internal strucure design: Vertical water inlet/outlet, added compressor discharge temp.sensor and protection, L-shaped evaporator ect., ensure much higher energy efficiency.
3. With WiFi control.
Specification
| Model No. | USP | 30R3-CP | 40R3-CP | 50R3-CP |
|
| Performance condition: Air temperature : 27°C, Inlet / Outlet water temerature: 26°C / 28°C, Humidity 80%. | |||||
| Heating capacity | kW | 3.2 | 4.14 | 5.23 | |
| Power consumption | kW | 0.56 | 0.73 | 0.83 | |
| C.O.P | W/W | 5.71 | 5.67 | 6.30 | |
| Performance condition: Air temperature : 15°C, Inlet / Outlet water temerature: 26°C / 28°C, Humidity 70%. | |||||
| Heating capacity | kW | 2.32 | 2.82 | 3.72 | |
| Power consumption | kW | 0.53 | 0.65 | 0.87 | |
| C.O.P | W/W | 4.37 | 4.34 | 4.27 | |
| Compressor | Rotary type with R32 refrigerant,GMCC or the similar brand. | ||||
| Voltage | 220-240V/50Hz/1PH | ||||
| Rated current | A | 3.1 | 3.2 | 5.1 | |
| Advised pool volume(covered) | m³ | 5~15 | 8~18 | 10~22 | |
| Water side heat exchanger | Spiral round titanium tube in PVC shell | ||||
| Water connection | mm | 32 or 38 | |||
| Noise level(1m) | dB(A) | 46 | 47 | 48 | |
| Net weight | kg | 20 | 21 | 24 | |
| Gross weight | kg | 23 | 24 | 26 | |
| Net Dimension(WxDxH) | mm | 416*387*433 | |||
| Packing Dimension(WxDxH) | mm | 480*420*480 | |||
