Home > Industrial Equipment & Components > Engine & Part > Engine > Jichai Brand Marine Engine Chidong Jinan Diesel Engine and Engine Parts H8190ZLC
Jichai Brand Marine Engine Chidong Jinan Diesel Engine and Engine Parts H8190ZLC
US$ 1 - 10000
MOQ: 1 Piece
Key Specifications
Get Latest Price
After-sales Service Provided:
Engineers available to service machinery overseas
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Jichai Brand Marine Engine Chidong Jinan Diesel Engine and Engine Parts 8190US$ 1 - 10000MOQ: 1 Piece -
JDEC JICHAI JINAN Chidong Marine DIESEL ENGINE 2000 DIESEL GENERATING SETSUS$ 1 - 1MOQ: 1 Piece
-
JDEC JICHAI JINAN DIESEL ENGINE 3000 B3000 DIESEL GENERATING SETSUS$ 1 - 1MOQ: 1 Piece
-
JDEC JICHAI JINAN CHIDONG MARINE DIESEL ENGINE 6000 DIESEL GENERATING SETSUS$ 1 - 1MOQ: 1 Piece
-
Jinan Diesel Engine Co,ltd Oil PumpUS$ 1 - 1MOQ: 1 Bag
After-sales Service Provided
Engineers available to service machinery overseas
| Series 600 marine diesel engines | |||||
| Model | Rated Power(kw/hp) | Rated speed(r/min) | Specific fuel consumption(g/kw’h) | Specific oil consumption(g/kw’h) | Overall dimension L*B*H(mm) |
| H12V190ZLC | 1580/2150 | 1450 | ≤200 | ≤1.0 | 3212*1597*2211 |
| H12V190ZLC2 | 1500/2040 | 1500 | ≤200 | ≤1.0 | 3212*1597*2211 |
| H12V190ZLC-1 | 1200/1630 | 1200 | ≤200 | ≤1.0 | 3212*1597*2211 |
| H16V190ZLC1 | 2400/3200 | 1500 | ≤200 | ≤1.0 | 3525*2060*2331 |
| H16V190ZLC | 2200/3000 | 1500 | ≤200 | ≤1.0 | 3525*2060*2331 |
| H16V190ZLC-1 | 1650/2240 | 1200 | ≤200 | ≤1.0 | 3525*2060*2331 |
| H8190ZLC | 1000/1360 | 1450 | ≤200 | ≤1.0 | 3349*1416*2225 |
| H8190ZLC-1 | 830/1120 | 1200 | ≤200 | ≤1.0 | 3349*1416*2225 |
| H8190ZLC-2 | 700/950 | 1000 | ≤200 | ≤1.0 | 3349*1416*2225 |
| H8190ZLC-3 | 900/1225 | 1300 | ≤200 | ≤1.0 | 3349*1416*2225 |
| Main technical data | |||||
| No. and arrangement of cylinders:12,60。Vee | |||||
| Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection | |||||
| Bore:190mm | |||||
| Stroke:215mm | |||||
| Total displacement:73.15/48.77L | |||||
| Compression ration:14.5:1 | |||||
| Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) | |||||
| Starting method:Air motor or electric motor | |||||
| Lubricating method:Pressure and splash lubrication |
