G6190ZLCZ-2R jichai brand marine engine chidong jinan diesel engine and engine parts

FOB Price

1 - 10000 / Piece

1 Piece(Min.Order)

Supply Ability 100 Piece / Pieces per Month
Payment Terms:T/T D/P D/A

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

After-sales Service Provided:

Engineers available to service machinery overseas

Product Description

			6 in-line marine diesel engines
Model	Rated Power(kw/hp)	Rated speed(r/min)	Specific fuel consumption(g/kw’h)	Specific oil consumption(g/kw’h)	Overall dimension LBH(mm)	Net weight(kg)
6190ZLC	450/610	1450	≤ 204	≤ 1.2	299012431763	3960
6190ZLC-1	400/540	1200	≤ 204	≤ 1.2	299012431763	3960
6190ZLC-2	330/450	1000	≤ 204	≤ 1.2	299012431763	3960
6190ZLC-3	400/540	1300	≤ 204	≤ 1.2	299012431763	3960
B6190ZLC	450/610	1450	≤ 204	≤ 1.2	300013241820	3960
B6190ZLCZ-R	450/610	1450	≤ 204	≤ 1.2	300013241820	3960
B6190ZLC-1	400/540	1200	≤ 204	≤ 1.2	300013241820	3960
B6190ZLCZ-1R	400/540	1200	≤ 204	≤ 1.2	300013241820	3960
B6190ZLC-2	330/450	1000	≤ 204	≤ 1.2	300013241820	3960
B6190ZLCZ-2R	330/450	1000	≤ 204	≤ 1.2	300013241820	3960
B6190ZLC-3	400/540	1300	≤ 204	≤ 1.2	300013241820	3960
B6190ZLCZ-3R	400/540	1300	≤ 204	≤ 1.2	300013241820	3960
G6190ZLC	540/740	1450	≤ 204	≤ 1.2	299512591754	4500
G6190ZLCZ-R	540/740	1450	≤ 204	≤ 1.2	299512591754	4500
G6190ZLC-R	540/740	1450	≤ 204	≤ 1.2	299512591754	4500
G6190ZLCZ	540/740	1450	≤ 204	≤ 1.2	299512591754	4500
G6190ZLC-1	450/610	1200	≤ 204	≤ 1.2	299512591754	4500
G6190ZLCZ-1R	450/610	1200	≤ 204	≤ 1.2	299512591754	4500
G6190ZLC-1R	450/610	1200	≤ 204	≤ 1.2	299512591754	4500
G6190ZLCZ-1	450/610	1200	≤ 204	≤ 1.2	299512591754	4500
G6190ZLC-2	380/520	1000	≤ 204	≤ 1.2	299512591754	4500
G6190ZLCZ-2R	380/520	1000	≤ 204	≤ 1.2	299512591754	4500
G6190ZLC-2R	380/520	1000	≤ 204	≤ 1.2	299512591754	4500
G6190ZLCZ-2	380/520	1000	≤ 204	≤ 1.2	299512591754	4500
G6190ZLC-3	480/650	1300	≤ 204	≤ 1.2	299512591754	4500
G6190ZLCZ-3R	480/650	1300	≤ 204	≤ 1.2	299512591754	4500
G6190ZLC-3R	480/650	1300	≤ 204	≤ 1.2	299512591754	4500
G6190ZLCZ-3	480/650	1300	≤ 204	≤ 1.2	299512591754	4500
Main technical data No. and arrangement of cylinders:6-cylinder,in-line Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection Bore:190mm Stroke:210mm Total displacement:35.73L Compression ration:14:1(6190,B6190),14.5:1(G6190) Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) Starting method:Air motor or electric motor Lubricating method:Pressure and splash lubrication

Contact Us

Shandong Hongfan Power Technology Co.,Ltd: Contact nameWang Jing; Phone86-1876-6952912; Addressshunhua road Ji'nan,Shandong
