G12V190ZLC1 jichai brand marine engine chidong jinan diesel engine and engine parts Z12V190BC1

FOB Price

1 - 10000 / Piece

1 Piece(Min.Order)

Product Details

After-sales Service Provided:

Engineers available to service machinery overseas

			Series 2000V marine diesel engines
Model	Rated Power(kw/hp)	Rated speed(r/min)	Specific fuel consumption(g/kw’h)	Specific oil consumption(g/kw’h)	Overall dimension LBH(mm)	Net weight(kg)
Z12V190BC1	800/1080	1500	≤209.4	≤1.6	264215882070	5300
Z12V190BC2	882/1200	1500	≤209.4	≤1.6	264215882070	5300
Z12V190BC8	1000/1360	1500	≤209.4	≤1.6	264215882070	5300
Z12V190BC9	882/1200	1500	≤209.4	≤1.6	264215882070	5300
Z12V190BC10	900/1225	1450	≤209.4	≤1.6	264215882070	5300
Z12V190BC11	882/1200	1500	≤209.4	≤1.6	264215882070	5300
G12V190ZLC1	1000/1360	1450	≤209.4	≤1.6	264215882070	5300
G12V190ZLC2	1000/1360	1450	≤209.4	≤1.6	264215882070	5300
Main technical data No. and arrangement of cylinders:12,60。Vee Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection Bore:190mm Stroke:210mm Total displacement:71.45L Compression ration:14:1 Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) Starting method:Air motor or electric motor Lubricating method:Pressure and splash lubrication










Model of generating set	Model of diesel engines	Model of generator	Rated Power KW	Rated voltage V	Rated frequency HZ	Overall dimension LBH(mm)	Net weight KG
CCFJ400/1000	Z12V190BCD-2	TFC5454-6JH42	400	390	50	421015002260	10500
CCFJ630/1500	Z12V190BCD	TFC5456-4JH42	630	390	50	426015002260	12000

Shandong Hongfan Power Technology Co.,Ltd: Contact nameWang Jing; Phone86-1876-6952912; Addressshunhua road Ji'nan,Shandong
