Strong Block Rare Earth Neodymium Cube / Rectangle Magnet

Strong Block Rare Earth Neodymium Cube / Rectangle Magnet thumbnail-1
Strong Block Rare Earth Neodymium Cube / Rectangle Magnet thumbnail-2
Strong Block Rare Earth Neodymium Cube / Rectangle Magnet thumbnail-3
Strong Block Rare Earth Neodymium Cube / Rectangle Magnet thumbnail-4
Strong Block Rare Earth Neodymium Cube / Rectangle Magnet photo-1
Strong Block Rare Earth Neodymium Cube / Rectangle Magnet photo-2
Strong Block Rare Earth Neodymium Cube / Rectangle Magnet photo-3
Strong Block Rare Earth Neodymium Cube / Rectangle Magnet photo-4
US$ 0.05 - 0.2 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
JLL
Place of Origin:
China
Model Number:
N35
Contact Supplier Request Quote Chat Now
Ningbo JLL International Trade Co.,Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name JLL
Place of Origin China
Model Number N35
Shape Other, Block
Type Permanent
Application Industrial Magnet
Composite NdFeB Magnet

Strong Block Rare Earth Neodymium Cube / Rectangle Magnet

Item Block/Rectangle/Square Magnet
Composition Neodymium Magnet
Application Voice-coil Motor(VCM), MRI, Generator, Car, Speaker, Computer
Working Temperature 80ºC~200ºC
Coating Zinc, Color Zinc, Nickel etc
Grade N35-N52, 38M-48M, 35H-48H, 33SH-44SH, 30UH-35UH
Dimension Customized size
Magnetism Direction Through thickness(Axially)+Radially
Type Strong&Permanent
Performance Permanent, Strong, Rust-proof, Anti-corrosion
Trade Term EXW, FOB, CIF, C&F ect.
Payment Term

TT, PayPal  ect.

Grade Parameter:

Grade Remanence Coercivity Force Intrinsic Coercive Force Max. Energy Product Working Temp.

Br Hcb Hcj (BH)max
mT kGs kA/m kOe kA/m kOe kJ/m3 MGOe
N35 1170-1220 11.7-12.2 ≥ 868 ≥ 10.9 ≥ 955 ≥ 12 263-287 33-36 80 ° C
N38 1220-1250 12.2-12.5 ≥ 899 ≥ 11.3 ≥ 955 ≥ 12 287-310 36-39 80 ° C
N40 1250-1280 12.5-12.8 ≥ 907 ≥ 11.4 ≥ 955 ≥ 12 302-326 38-41 80 ° C
N42 1280-1320 12.8-13.2 ≥ 915 ≥ 11.5 ≥ 955 ≥ 12 318-342 40-43 80 ° C
N45 1320-1380 13.2-13.8 ≥ 923 ≥ 11.6 ≥ 955 ≥ 12 342-366 43-46 80 ° C
N48 1380-1420 13.8-14.2 ≥ 923 ≥ 11.6 ≥ 876 ≥ 12 366-390 46-49 80 ° C
N50 1400-1450 14.0-14.5 ≥ 796 ≥ 10.0 ≥ 876 ≥ 11 382-406 48-51 60 ° C
N52 1430-1480 14.3-14.8 ≥ 796 ≥ 10.0 ≥ 876 ≥ 11 398-422 50-53 60 ° C
35M 1170-1220 11.7-12.2 ≥ 868 ≥ 10.9 ≥ 1114 ≥ 14 263-287 33-36 100 ° C
38M 1220-1250 12.2-12.5 ≥ 899 ≥ 11.3 ≥ 1114 ≥ 14 287-310 36-39 100 ° C
40M 1250-1280 12.5-12.8 ≥ 923 ≥ 11.6 ≥ 1114 ≥ 14 302-326 38-41 100 ° C
42M 1280-1320 12.8-13.2 ≥ 955 ≥ 12.0 ≥ 1114 ≥ 14 318-342 40-43 100 ° C
45M 1320-1380 13.2-13.8 ≥ 995 ≥ 12.5 ≥ 1114 ≥ 14 342-366 43-46 100 ° C
48M 1360-1430 13.6-14.3 ≥ 1027 ≥ 12.9 ≥ 1114 ≥ 14 366-390 46-49 100 ° C
50M 1400-1450 14.0-14.5 ≥ 1033 ≥ 13.0 ≥ 1114 ≥ 14 382-406 48-51 100 ° C
35H 1170-1220 11.7-12.2 ≥ 868 ≥ 10.9 ≥ 1353 ≥ 17 263-287 33-36 120 ° C
38H 1220-1250 12.2-12.5 ≥ 899 ≥ 11.3 ≥ 1353 ≥ 17 287-310 36-39 120 ° C
40H 1250-1280 12.5-12.8 ≥ 923 ≥ 11.6 ≥ 1353 ≥ 17 302-326 38-41 120 ° C
42H 1280-1320 12.8-13.2 ≥ 955 ≥ 12.0 ≥ 1353 ≥ 17 318-342 40-43 120 ° C
45H 1300-1360 13-13.6 ≥ 963 ≥ 12.1 ≥ 1353 ≥ 17 326-358 43-46 120 ° C
48H 1370-1430 13.7-14.3 ≥ 995 ≥ 12.5 ≥ 1353 ≥ 17 366-390 46-49 120 ° C
33SH 1130-1170 11.3-11.7 ≥ 844 ≥ 10.6 ≥ 1592 ≥ 20 247-271 31-34 150 ° C
35SH 1170-1220 11.7-12.2 ≥ 876 ≥ 11.0 ≥ 1592 ≥ 20 263-287 33-36 150 ° C
38SH 1220-1250 12.2-12.5 ≥ 907 ≥ 11.4 ≥ 1592 ≥ 20 287-310 36-39 150 ° C
40SH 1240-1280 12.5-12.8 ≥ 939 ≥ 11.8 ≥ 1592 ≥ 20 302-326 38-41 150 ° C
42SH 1280-1320 12.8-13.2 ≥ 987 ≥ 12.4 ≥ 1592 ≥ 20 318-342 40-43 150 ° C
45SH 1320-1380 13.2-13.8 ≥ 1003 ≥ 12.6 ≥ 1592 ≥ 20 342-366 43-46 150 ° C
30UH 1080-1130 10.8-11.3 ≥ 812 ≥ 10.2 ≥ 1990 ≥ 25 223-247 28-31 180 ° C
33UH 1130-1170 11.3-11.7 ≥ 852 ≥ 10.7 ≥ 1990 ≥ 25 247-271 31-34 180 ° C
35UH 1180-1220 11.8-12.2 ≥ 860 ≥ 10.8 ≥ 1990 ≥ 25 263-287 33-36 180 ° C
38UH 1220-1250 12.2-12.5 ≥ 876 ≥ 11.0 ≥ 1990 ≥ 25 287-310 36-39 180 ° C
40UH 1240-1280 12.5-12.8 ≥ 899 ≥ 11.3 ≥ 1990 ≥ 25 302-326 38-41 180 ° C

Our Company

Ningbo JLL International Trade Co.,Ltd. Specializing in the production and sale of magnetic
NdFeB, magnetic bar, magnetic products, magnetic frame. Magnets of various shapes and sizes
can be produced according to customer requirements, such as packaging diskette, the motor
magnetic tile, magnetic ring, toy bar magnet, magnetic ball, with the exception of iron magnetic rods,
magnetic hooks, magnetic separator box; Surface treatment: Gold, silver, plated epoxy, nickel-plated
copper-nickel, zinc, chromium, titanium (blue zinc, black zinc, color zinc), above the surface
treatment to meet environmental requirements.

Rectangle / Cube Shape Rare Earth Magnet Block Super Strong Neodymium Magnets


Grade Remanence Coercivity Force Intrinsic Coercive Force Max. Energy Product Working Temp.

Br Hcb Hcj (BH)max
mT kGs kA/m kOe kA/m kOe kJ/m3 MGOe
N35 1170-1220 11.7-12.2 ≥ 868 ≥ 10.9 ≥ 955 ≥ 12 263-287 33-36 80 ° C
N38 1220-1250 12.2-12.5 ≥ 899 ≥ 11.3 ≥ 955 ≥ 12 287-310 36-39 80 ° C
N40 1250-1280 12.5-12.8 ≥ 907 ≥ 11.4 ≥ 955 ≥ 12 302-326 38-41 80 ° C
N42 1280-1320 12.8-13.2 ≥ 915 ≥ 11.5 ≥ 955 ≥ 12 318-342 40-43 80 ° C
N45 1320-1380 13.2-13.8 ≥ 923 ≥ 11.6 ≥ 955 ≥ 12 342-366 43-46 80 ° C
N48 1380-1420 13.8-14.2 ≥ 923 ≥ 11.6 ≥ 876 ≥ 12 366-390 46-49 80 ° C
N50 1400-1450 14.0-14.5 ≥ 796 ≥ 10.0 ≥ 876 ≥ 11 382-406 48-51 60 ° C
N52 1430-1480 14.3-14.8 ≥ 796 ≥ 10.0 ≥ 876 ≥ 11 398-422 50-53 60 ° C
35M 1170-1220 11.7-12.2 ≥ 868 ≥ 10.9 ≥ 1114 ≥ 14 263-287 33-36 100 ° C
38M 1220-1250 12.2-12.5 ≥ 899 ≥ 11.3 ≥ 1114 ≥ 14 287-310 36-39 100 ° C
40M 1250-1280 12.5-12.8 ≥ 923 ≥ 11.6 ≥ 1114 ≥ 14 302-326 38-41 100 ° C
42M 1280-1320 12.8-13.2 ≥ 955 ≥ 12.0 ≥ 1114 ≥ 14 318-342 40-43 100 ° C
45M 1320-1380 13.2-13.8 ≥ 995 ≥ 12.5 ≥ 1114 ≥ 14 342-366 43-46 100 ° C
48M 1360-1430 13.6-14.3 ≥ 1027 ≥ 12.9 ≥ 1114 ≥ 14 366-390 46-49 100 ° C
50M 1400-1450 14.0-14.5 ≥ 1033 ≥ 13.0 ≥ 1114 ≥ 14 382-406 48-51 100 ° C
35H 1170-1220 11.7-12.2 ≥ 868 ≥ 10.9 ≥ 1353 ≥ 17 263-287 33-36 120 ° C
38H 1220-1250 12.2-12.5 ≥ 899 ≥ 11.3 ≥ 1353 ≥ 17 287-310 36-39 120 ° C
40H 1250-1280 12.5-12.8 ≥ 923 ≥ 11.6 ≥ 1353 ≥ 17 302-326 38-41 120 ° C
42H 1280-1320 12.8-13.2 ≥ 955 ≥ 12.0 ≥ 1353 ≥ 17 318-342 40-43 120 ° C
45H 1300-1360 13-13.6 ≥ 963 ≥ 12.1 ≥ 1353 ≥ 17 326-358 43-46 120 ° C
48H 1370-1430 13.7-14.3 ≥ 995 ≥ 12.5 ≥ 1353 ≥ 17 366-390 46-49 120 ° C
33SH 1130-1170 11.3-11.7 ≥ 844 ≥ 10.6 ≥ 1592 ≥ 20 247-271 31-34 150 ° C
35SH 1170-1220 11.7-12.2 ≥ 876 ≥ 11.0 ≥ 1592 ≥ 20 263-287 33-36 150 ° C
38SH 1220-1250 12.2-12.5 ≥ 907 ≥ 11.4 ≥ 1592 ≥ 20 287-310 36-39 150 ° C
40SH 1240-1280 12.5-12.8 ≥ 939 ≥ 11.8 ≥ 1592 ≥ 20 302-326 38-41 150 ° C
42SH 1280-1320 12.8-13.2 ≥ 987 ≥ 12.4 ≥ 1592 ≥ 20 318-342 40-43 150 ° C
45SH 1320-1380 13.2-13.8 ≥ 1003 ≥ 12.6 ≥ 1592 ≥ 20 342-366 43-46 150 ° C
30UH 1080-1130 10.8-11.3 ≥ 812 ≥ 10.2 ≥ 1990 ≥ 25 223-247 28-31 180 ° C
33UH 1130-1170 11.3-11.7 ≥ 852 ≥ 10.7 ≥ 1990 ≥ 25 247-271 31-34 180 ° C
35UH 1180-1220 11.8-12.2 ≥ 860 ≥ 10.8 ≥ 1990 ≥ 25 263-287 33-36 180 ° C
38UH 1220-1250 12.2-12.5 ≥ 876 ≥ 11.0 ≥ 1990 ≥ 25 287-310 36-39 180 ° C
40UH 1240-1280 12.5-12.8 ≥ 899 ≥ 11.3 ≥ 1990 ≥ 25 302-326 38-41 180 ° C


Payment Term:
T/T, L/C, PayPal.

Package & Shipment:
1. By Express(DHL, FedEx, TNT, UPS ect): Door to door, Short Delivery time, 3-5 days.
2. By Air: Short Delivery Time, 3-7 days.
3. By Sea: Cheap Shipping Cost, 7-30 days.


Package: Magnetic Isolation Package
Carton: 36*27*15CM

Rectangle / Cube Shape Rare Earth Magnet Block Super Strong Neodymium Magnets

FAQ:
1. How to get prompt quotation?
Kindly offer us the specific size, quantity, coating(zinc/nickel), magnetism direction ect other
requiries. Then best price will be offered ASAP.

2.What about the lead time?
(1) Sample: 5-7 days.
(2)  Batch quantity: 7-12 days.

3.What's the MOQ?
(1) Spot Stocks: No MOQ;
(2) Regular Size: 500 PCS, 1000 PCS, 2000 PCS, 5000 PCS ect.
(3) Other Size: 2000 PCS, 5000 PCS, 10000 PCS ect.

4. Terms of Paymemt:
(1). T/T in advance(telegraphic transfer-bank order)
(2). Western Union cash - for small order or samples order.
(3). PayPal- for small order, quick receipt

Please feel free to contact me for any questions and requiries.
