hi precision slant bed cnc lathe mill live tooling milling combo turning center machine CK46D-8
The Machine Tool is slant bed Turn-Milling Machine, which has X, Y, Z, C axis, and controlled by servo motor. It has a compact and reasonable structure, the spindle (C axis) driven by servo motor. This machine not only can turn excircle, end face, thread of Rod type and Plate type work piece in kinds of material, but also can mill, drill kinds of radial and axial hook face, etc. many kinks processes. This machine is suitable to process small work piece in a high efficient.
Main specifications:
SPECIFICATIONS |
Units |
CK46D-8 |
Swing over bed |
mm |
450 |
Swing over cross slide |
mm |
130 |
Distance between centers |
mm |
450 |
Spindle bore |
mm |
56 |
Spindle nose type |
- |
A2-5 |
Spindle speed range |
rpm |
50-4500 |
Turret/tool post |
- |
Hydraulic turret 4+4 living tools |
X axis travel |
mm |
500 |
Z axis travel |
mm |
450 |
Y axis travel |
mm |
240 |
X axis rapid traverse |
mm/min |
24000 |
Z axis rapid traverse |
mm/min |
24000 |
Y axis rapid traverse |
mm/min |
15000 |
living tools type |
- |
Nose 4+ Side 4 |
living tools power |
kw |
1.3 |
living tools speed |
r/min |
3000 |
Distance of each living tools |
mm |
60 |
X/Y/Z Positioning accuracy |
mm |
0.003mm |
X/Y/Z repositioning accuracy |
mm |
0.006mm |
Spindle (C Axis) dividing positioning accuracy |
” |
0.02” |
Spindle (C Axis) dividing repositioning accuracy |
” |
0.006” |
Main spindle (C Axis) motor |
kw |
C Axis 7.5 |
Guide rail type |
- |
Linear rail |
Machine weight |
kg |
3000 |
Overall dimension |
mm |
2500x1750x1800 |
