3 Axis Mini Size Small VMC320 Cnc Vertical Machining Center Cheap
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3/ Four-axis CNC Vertical Machining Center VMC650 With AtcNegotiableMOQ: 1 -
Luxing Cnc Metal Milling Machine XK7136 Vertical Machining CenterNegotiableMOQ: 1
-
High Speed VMC 8000rpm 10000rpm Vertical Machining Center V65 VMC650 Cnc Milling Machine Price for SaleNegotiableMOQ: 1
-
High Precision 3/4/5 Axis VMC850 FANUC Control Cnc Milling Machine Vertical Machining Center PriceNegotiableMOQ: 1
-
New 3/4-axis VMC850 Cnc Vertical Metal Machining CenterNegotiableMOQ: 1
3 axis mini size small VMC320 cnc vertical machining center cheap
Product Characteristics:
1. Precision BT30 Spindle
2. High precision ball screw
2. High precision ball screw
3. Linear rail guide.
4. Fully-guarded type machine
4. Fully-guarded type machine
Product Main Specifications:
Specifications | Unit | VMC320 |
Table Size (L*W) | mm | 600×200 |
Max. table load | kg | 100 |
Travel of x,y,z axis | mm | 300/200/300 |
Spindle nose to table surface distance | mm | 80-350 |
Spindle taper | -- | BT30 |
Spindle speed range | rpm | 100-5000 |
Spindle motor power | KW | 1.5 |
Rapid traverse X/Y/Z axis | m/min | 6/6/6 |
Cutting feed of X/Y/Z axis | mm/min | 1-3000 |
Guide way type | linear rail | |
Tool Magazine Capacity | tools | 8T Hat type (optional,need add extra cost) |
Positioning accuracy | mm | ±0.01/300 |
Machine Weight | Kg | 1200 |
Dimension | mm | 1600×1500×2000 |
Details:
FAQ:
1:How can I choose the most suitable machines?
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine and so on .
3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.
4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.
5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
7: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
