VMC7035 Cnc Milling Machine Mitsubishi Control 3/4 Axis Vertical Machining Center Cheap Economical High Precision

VMC7035 Cnc Milling Machine Mitsubishi Control 3/4 Axis Vertical Machining Center Cheap Economical High Precision photo-1
VMC7035 Cnc Milling Machine Mitsubishi Control 3/4 Axis Vertical Machining Center Cheap Economical High Precision photo-2
VMC7035 Cnc Milling Machine Mitsubishi Control 3/4 Axis Vertical Machining Center Cheap Economical High Precision photo-3
VMC7035 Cnc Milling Machine Mitsubishi Control 3/4 Axis Vertical Machining Center Cheap Economical High Precision photo-4
VMC7035 Cnc Milling Machine Mitsubishi Control 3/4 Axis Vertical Machining Center Cheap Economical High Precision photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

VMC7035 cnc milling machine mitsubishi control 3/4 axis vertical machining center cheap economical high precision

Product Description

Product Characteristics:

1. Taiwan BT40 Spindle

2. Taiwan ball screw and locking nut

3. Umbrella type tool Magazine, 12 tools

4. Fully-guarded type machine

Product Main Specifications:

Specifications

Unit

VMC7032

VMC7035

Table Size (L*W)

mm

800×350

950×350

Max. table load

kg

400

400

Travel of x,y,z axis

mm

610/320/500

610/350/500

Spindle nose to table surface distance

mm

150-650

150-650

T-slot Size

mm

3-14-80

3-14-100

Spindle center to Column guide distance

mm

410

410

Spindle taper

 --

BT40

BT40

Spindle speed range

rpm

80-8000

80-8000

Spindle motor power

KW

3.7/5.5

3.7/5.5

Spindle drive

 --

Belt transmission

Belt transmission

Positioning accuracy

mm

0.015

0.015

Repeat Positioning accuracy

mm

0.010

0.010

Rapid traverse X/Y/Z axis

m/min

15/15/12

15/15/12

Cutting feed of X/Y/Z axis

mm/min

1-5000

1-5000

Tool Magazine Capacity

tools

12 Hat type

12 Hat type

Machine Weight

Kg

3000

3200

Dimension

mm

2290×1805×1900

2300×2200×2300

Voltage

 --

Customized

Customized

Details
Packaging & Shipping
Company Information
Exhibitions
FAQ

 1:How can I choose the most suitable machines?
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .



2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine and so on .


3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.


4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.


5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.


6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .


7: What's the MOQ?

A: 1 set .(Only some low cost machines will be more than 1 set )
