Smart portable blue laser 3d scanner for all industries
All our products are self-developed with priprietary intelletual property rights.
The RigelScanTM series handheld blue laser 3D scanner, is a new metroloty system launched by ZG Technology Co., Ltd. RigelScanTM can capture fine features of the parts with an accuracy up to 0.02mm, certified by National Institute of Metrology. RigelScanTM applies blue laser scanning technology for fine scanning of structures. In the mean time, RigelScanTM can be equipped with wireless module, for more easy and flexible scanning experience of large parts. Thus, RigelScanTM provides the perfect 3D
measurement solution for all industries.
measurement solution for all industries.
Product Features
1. Reliable inspection result.2. Self-positioning.
3. Portable, lightweight and free movement.
4. Ultra high accuracy.
5. 14 laser lines 480,000 measures/s + 1 extra line for hard-to-reach areas.
6. Automatic mesh output, seamless connection with 3D software.
7.Wireless connection.
8. Real-time visualization of your scan.
9. Simple 3D scanning process.
10. Scanned data is compatible to most 3D software;
11. Exports .stl, .obj, .ascii and other file formats.
SPECIFICATION: RigelScanTM RigelScan EliteTM |
GScan |
|||
MEASUREMENT RATE
|
205,000measurements/s
|
480,000measurements/s
|
||
SCANNING AREA |
225×250mm |
275×250mm |
||
LIGHT SOURCE |
6 laser line(+ extra 1 line, +5 parallel laser lines ) |
14 laser line(+extra 1 line, +5 parallel laser lines ) |
||
LASER CLASS |
CLASS ΙΙ(eye-safe) |
-- |
||
RESOLUTION |
0.05mm |
0.03mm |
||
ACCURACY |
up to 0.03 mm |
up to 0.02mm |
||
VOLUMETRIC ACCURACY |
0.03+0.06mm/m |
0.02+0.06mm/m |
||
VOLUMETRIC ACCURACY (COMBINED WITH PHOTOSHOT) |
0.03+0.025mm/m |
0.02+0.025mm/m |
||
STAND-OFF DISTANCE |
300 mm |
|||
DEPTH OF FIELD |
250 mm |
|||
