High Precision Industrial 3d Scanner 3d Laser Scanner for Cnc Router Machine Model
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Precision Industrial Blue Light 3d Scan 3d Scanner for Cnc Router Machine ModelNegotiableMOQ: 1 -
More Easy and Flexible Handheld Blue Laser 3D ScannerNegotiableMOQ: 1
-
Digital 3D Scanner Mobile Handheld Laser Scanner 3DNegotiableMOQ: 1
-
Industry Grade Optical Tracking 3D Scanner With High AccuracyNegotiableMOQ: 1
-
CMM Probe M2 Ruby Ball Stylus With Tungsten Carbide StemNegotiableMOQ: 1
Product line
GScan
Smart Full-Color 3D Scanner
ZGScan (Laser)
Smart Handheld 3D Scanner
AalaScan(Versatile)
Metrology-grade 3D laser scanner
PhotoShot
Smart 3D Photogrammeter
AutoMetric
Smart Inline Inspection System
AltairScanRigelScan (Blue Laser)
Smart Handheld 3D Scanner
HyperScan717/919/DX + ZG Probe
Smart Optical Tracking 3D Scanner
Specifications
GScan
--- Smart Full-Color 3D Scanner
True full-Color
--Highly real color reflection
Portability
--weight is under 0.56Kg
--weight is under 0.56Kg
Multifunction Scanning
--Handheld & Fixed mode
High Speed Scanning
--550,000 measurements/s
Friendly Operation
--Easy operation/10 minutes to grasp
Visualization
--Real-time scanning data display
Detail Data
MODEL | GScan | ||
SCANNING MODE
| Hand-Held
| Fixed
| |
PROJECTION MODE | Speckle/Stripe Projection | Grating stripe project | |
ACCURAC | up to 0.1 mm | up to 0.05 mm | |
VOLUMETRIC ACCURACY | 0.3 mm/m | -- | |
MEASUREMENT RATE | 550,000 measurements/s | Single Scanning＜2s | |
RESOLUTION | up to 0.1 mm | 0.1 mm | |
RECOMMENDED OBJECT SIZE | 0.15-4.00 m | 0.03-0.25 m | |
POSITIONING METHOD | Geometry, Targets, Combination | Turntable positioning,Geometry, Targets | |
STAND-OFF DISTANCE | 400 mm | ||
DEPTH OF FIELD | 200 mm | ||
SINGLE SCANNING | 250 × 185 mm | ||
LIGHT SOURCE | White light | ||
TEXTURE MAPPING | 1 Pixel | ||
CONNECTION | USB 3.0 | ||
OPERATION SYSTEM | Win7 (64bit)、 Win10 (64bit) | ||
WEIGHT | 0.56 kg | ||
SIZE | 280 × 130 × 50 mm | ||
OPERATING TEMPERATURE RANGE | -20 ~ 40 °C | ||
OPERATING HUMIDITY RANGE (NON-CONDENSE) | 10 ~ 90% | ||
OUTPUT FARMATS | .stl, .obj, .wrl, .ply, .txt, .xyz, .asc etc, customizable | ||
COMPATIBLE SOFTWARE | 3D Systems (Geomagic Solutions)、InnovMetric Software (PolyWorks)、Dassault、Systemes (CATIA V5 / SolidWorks)、 PTC (Pro / ENGINEER)、Siemens (NX / Solid Edge)、 Autodesk (Inventor、Alias、3ds Max、Maya、Softimage) | ||
Application Fields
On-site Scanning in India Tradeshow
Product packaging
About us
UNIMETRO helps you to build your own business!
UNIMETRO is the professional manufacturer of metrology with over 10 years experience. We offer high performance products with reasonable price. And professional cooperators from global market are always welcome to join us and UNIMETRO will always offer the best marketing and technical support.
Our service
Unimetro focus on per step in business process including the design, manufacture, installation and after sales service.
On-site service and guidance:
* 24 Hours online by phone, email, whatsup, skype, youtube, facebook…etc.
* Spot stock, Fast delivery
* After sale service
1 year warranty service and Free test software upgrades.
Technical training for technical engineers.
Provide matching testing solutions.
Site installation equipment and usage instructions.
On-site service and guidance:
* 24 Hours online by phone, email, whatsup, skype, youtube, facebook…etc.
* Spot stock, Fast delivery
* After sale service
1 year warranty service and Free test software upgrades.
Technical training for technical engineers.
Provide matching testing solutions.
Site installation equipment and usage instructions.
