45kw 50kg Gold Melting Furnace For Sale
- 1000 per Month
- T/T Credit Card
- mini aluminum scrap melting furnace
- electrical oven to melt gold/ silver/ copper/ steel
- portable induction melting furnace for gold smelting
- 50kg Aluminum Melting Oven For Cast Iron, Steel, Bronze
- 100Kg Cast Iron, Steel, Copper Melting Furnace Prices
- Mini Cast Iron Melting Induction Furnace With Medium Frequency
Product Description
45kw 50kg Gold Melting Furnace For Sale
1. Brief introduction
Small medium frequency induction melting furnace is mainly used for the melting of iron, steel, stainless steel, copper, brass, silver, gold ,glass, aluminium, alloys and metal ores. Melting capacity of induction melting furnace can be from 0.5KG to 500KG.
50kg gold melting furnace is equipped with a induction coil inside of the furnace body, and a pure graphite crucible surrounded by induction coil, when the power on, with the induction effect, the melting furnace will produce high temperature up to 3000°C in very short time, and do the melting process. The power of small induction melting furnace can be displayed and adjusted through the rotary switch on the control panel.
2. Features
• Adopts IGBT medium frequency power supply, energy saved 20% at least compared with silicon controlled rectifier type.
• All-around protection functions: overcurrent protection, hydropenia protection, overheating protection, overvoltage protection, short circuit protection, lacking phase protection, etc.
• Optimal panel display such as frequency display, current display, voltage display, power display, make the equipment work condition intuitionistic, induction coil design and capacitance adjustment beneficial.
• Super small size and portable, occupies not enough 1.0 square meters, suitable for small scale production, school laboratory and other similar situations.
• 24 hours nonstop melting ability, long use life.
• Outstanding stirring action, conductive to the uniformity of melting temperature and metal structure, dross, and impurities decrease.
• Convenient to replace oven for different materials.
• Available for melting many kinds of materials: steel, stainless steel, iron, copper, aluminum, gold, silver, zinc, metal alloys, iron ore, gold ore, etc.
• Fast melting rate, 20~30 minutes for small amount melting, 30~60 for large amount melting.
• Using crucible: no need to make lining with refractory materials by skilled person as the normal induction oven.
3. Composition of the furnace
1). IGBT Medium frequency induction heating power supply
2). 50kg gold melting furnace body
3). Compensation capacitor
4). Water cooled cables
5). Pure graphite crucible for induction melting furnace
Model | Max.input power | Melting Capacity of Furnace | ||
Steel,stainless steel ,cast iron | Copper ,bronze,brass,silver,gold | Aluminum,aluminum alloy | ||
IGBT-15 | 15 | 3 | 10 | 3 |
IGBT-25 | 25 | 5 | 20 | 5 |
IGBT-35 | 35 | 10 | 30 | 10 |
IGBT-45 | 45 | 18 | 50 | 18 |
IGBT-70 | 70 | 25 | 100 | 25 |
IGBT-90 | 90 | 40 | 120 | 40 |
IGBT-110 | 110 | 50 | 150 | 50 |
IGBT-160 | 160 | 100 | 250 | 100 |
Model | IGBT-15 | IGBT-25 | IGBT-35 | IGBT-45 | IGBT-70 | IGBT-90 | IGBT-110 | IGBT-160 |
Input power (KW) | 15 | 25 | 35 | 45 | 70 | 90 | 110 | 160 |
Output current (A) | 3~22 | 5~45 | 10~70 | 15~95 | 20~130 | 25~170 | 30~200 | 35~290 |
Output voltage (V) | 70~520 | 70~550 | ||||||
Input power supply | 3 Phase, 380V±20%, 50Hz or 60 Hz | |||||||
Input oscillating frequency | 1KHz~20KHz depends on customers' requirements to workpiece | |||||||
Duty cycle | 100% 24 hours continuous working | |||||||
Power supply wight (KG) | 24 | 24 | 34 | 36 | 51 | 57 | 89 | 100 |
Volume of power cabinet (cm) | 46×27×45 | 65×35×55 | 75×40×87 | 75×50×87 |
Furnace body:
1. Manual gear box tilting type
2. Electrical gear box tilting type
3. Hydraulic tilting type
Power Control Cabinet:
Induction coil:
Made of copper, heating inductor in the furnace
Crucibles:
Melting Site:
* Inquiry and consulting support.
* Factory visit, spot demo, free sample test,
* Free main circuit diagram, machine operation manual support.
* Training how to use and maintain the machine.
* Online technical support, fast solution.
* Replaced parts will be offerer at favourable prices.
