Y/G CABLE ELECTRIC WIRE
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
- Successful sale pvc coated double core electric wire under IEC
- top quality 16 mm ground cable with 6 mm crimp ring terminal
- UV resistant Type RRU Shield 300V for outdoor UV resistant power cable
- Hot selling solar photovoltaic cable 6mm2
- Buy now pay later UL1015/AWM 1015 hook up wire 16awg PVC insulated electric wire
- Buy now pay later size 1015/AWM 1015 hook up wire stranded 12awg PVC insulated electric wire
Product Description
Specifications for pvc insulated copper yellow and green cable wire:
1. 450v/750v
2. pvc insulated
3. 100 meters per coil
Types: Cross-section area---1.5mm2, 2.5mm2, 4mm2, 6mm2, 10mm2, 16mm2.
Type | Name | Laying place and requirement | Long term working temperature |
227IEC01/05 BV BLV |
Copper conductor PVC insulated wires | Fixed laid indoors,conduits etc. | 70 |
Aluminum Conductor PVC insulated wires | |||
227IEC07 BV-90 |
Heat resistant copper conductor PVC insulated wires at 90 | Mainly be laid at the places of high temperature environment and can be laid indoors,conduits. | 90 |
BVR | Copper conductor PVC insulated flexible wire | Be for laying permanent place where flexible required | 70 |
227IEC10 BW |
Copper conductor PVC insulated PVC sheathed round wires | Fixed laid,fit for the places with high mechanical protection and moisture place.Can be laid in the air or underground. | 70 |
BLW | Aluminum conductor PVC insulated PVC sheathed round wires | ||
BWB | Copper conductor PVC insulated PVC Sheathed flat wires | ||
BLWB | Aluminum conductor PVC insulated sheathed flat wires | ||
227IEC02RV 227IEC06RV |
Copper conductor PVC insulated flexible connector | Mainly used at middle and linht stylemoving electronics,home appliances,power and lighting and the places where flexible required. | 70 |
227IECC42 RVB |
Copper conductor PVC insualted flat flexible connector | ||
RVS | Copper conductor PVC insulated flexible twisting connector wire | ||
227IEC52 RW 227IEC53 RW |
Copper conductor PVC insulated PVC sheated round flexible connector(light and common type) |
Comprehensive Data table of BV BLV Type PVC insualted wire
Nominal sectional area mm2 |
Conductor No/Dia. mm |
Nominal Insulated thick mm |
Max overall Dia. mm |
Condcutor Resistance at 20 |
Min insulated resistance at 70MΩ/km |
Weight Kg/km |
||
Cu | Al | Cu | Al | |||||
1.5 | 1/1.38 | 0.7 | 3.3 | 12.1 | - | 0.011 | 19.2 | - |
1.5 | 7/0.52 | 0.7 | 3.5 | 12.1 | - | 0.010 | 20.6 | - |
2.5 | 1/1.78 | 0.8 | 3.9 | 7.41 | 11.8 | 0.010 | 30.8 | 15.0 |
4 | 1/2.25 | 0.8 | 4.4 | 4.61 | 7.39 | 0.0085 | 45.5 | 21.0 |
6 | 1/2.76 | 0.8 | 4.9 | 3.08 | 4.91 | 0.0070 | 65.0 | 29.0 |
10 | 7/1.35 | 1.0 | 7.0 | 1.83 | 3.08 | 0.0065 | 110.0 | 52.0 |
16 | 7/1.70 | 1.0 | 8.0 | 1.15 | 1.91 | 0.0050 | 170.0 | 70.0 |
25 | 7/2.14 | 1.2 | 10.0 | 0.727 | 1.20 | 0.0050 | 270.0 | 110.0 |
35 | 7/2.52 | 1.2 | 11.5 | 0.524 | 0.868 | 0.0040 | 364.0 | 150.0 |
50 | 19/1.78 | 1.4 | 13.0 | 0.387 | 0.641 | 0.0045 | 500.0 | 200.0 |
70 | 19/2.14 | 1.4 | 15.0 | 0.268 | 0.443 | 0.0035 | 688.0 | 269.0 |
95 | 19/2.52 | 1.6 | 17.5 | 0.193 | 0.320 | 0.0035 | 953.0 | 360.0 |
120 | 37/2.03 | 1.6 | 19.0 | 0.153 | 0.253 | 0.0032 | 1168.0 | 449.0 |
150 | 37/2.25 | 1.8 | 21.0 | 0.124 | 0.206 | 0.0032 | 1466.0 | 551.0 |
185 | 37/2.52 | 2.0 | 32.5 | 0.099 | 0.164 | 0.0032 | 1808.0 | 668.0 |
Type BVR 450/750V copper conductor PVC insulate flexible wire
Nominal sectional area mm2 |
Conductor No/Dia. mm |
Nominal Insulated thick mm |
Max overall Dia. mm |
Condcutor Resistance at 20 |
Min insulated resistance at 70MΩ/km |
Weight Kg/km |
2.5 | 9/0.41 | 0.8 | 4.2 | 7.41 | 0.011 | 33.0 |
4 | 19/0.52 | 0.8 | 4.8 | 4.61 | 0.009 | 48.0 |
6 | 19/0.64 | 0.8 | 5.6 | 3.08 | 0.0084 | 68.0 |
10 | 49/0.52 | 1.0 | 7.6 | 1.83 | 0.0072 | 115.0 |
16 | 49/0.64 | 1.0 | 8.8 | 1.15 | 0.0062 | 176.0 |
25 | 98/0.58 | 1.2 | 11.0 | 0.727 | 0.0058 | 272.0 |
35 | 133/0.58 | 1.2 | 12.5 | 0.524 | 0.0052 | 384.0 |
50 | 133/0.68 | 1.4 | 16.5 | 0.387 | 0.0051 | 510.0 |
70 | 189/0.68 | 1.4 | 16.5 | 0.268 | 0.0045 | 714.0 |
95 | 259/0.68 | 1.6 | 19.5 | 0.139 | 0.0035 | 965.0 |
120 | 259/0.76 | 1.8 | 22.0 | 0.153 | 0.0032 | 1210.0 |
150 | 259/0.85 | 1.8 | 25.0 | 0.124 | 0.0032 | 1510.0 |
Any inquiries, pls feel free to contact me~~
