1.5mm 2.5mm 4mm 6mm pvc wire
Application
These wire are Widely used in buildings or outdoors ,applied in household electric appliances,instrumentation and telecommunications equipment and other occasions.
Operating features
1. Permissible long-term working temperature: normal cable is 70°C,heat resistance 90°C.
2. Cable laying temperature: not less than 0 °C
3. Permissible bending radius: diameter (D) is less than 25mm, the allow bending radius should be not less than 4D, cable diameter (D) is 25mm and above, the allow bending radius should be not less than 6D
Type and Description of cable
Type |
Description |
Core |
Area mm2 |
Voltages |
Standard |
|
227IEC01 BV |
Single-core hard drawn non-sheathed cable |
1 |
1.5-400 |
400/750 |
GB5023.3 |
|
227IEC01 RV |
Single-cote soft draen non-sheafhed cable |
1 |
1.5-240 |
400/750 |
|
|
227IEC05 BV |
Single-core solid conductor drawn non sneathed cable for internal wiring is70 |
11 |
0.5-1.0 |
300/500 |
|
|
227IE06 RV |
Single-cote soft drwn non sheathed cable for internal wiring is 70 |
1 |
0.5-1.0 |
300/500 |
|
|
227IEC07 BV-90 |
Single-core solid conductor draw non sneathed cable for internal wiring is 90 |
1 |
0.5-2.5 |
300/500 |
|
|
227IEC08 RV-90 |
Single-core soft drawn non sheathde cable for internal wiring is90 |
1 |
0.5-2.5 |
300/500 |
|
227IEC10(BVV) |
Light PVC sheathed cable |
2-5 |
1.5-30 |
300/500 |
GB5023.4 |
227IEC52(RVV) |
Light PVC sheathed soft wires |
2 ,3 |
0.5-0.75 |
300/500 |
GB5023.5 |
227IEC53(RVV) |
Ordinary PVC sheathed soft wries |
2-5 |
0.75-2.5 |
300/500 |
|
BV |
CU-core PVC insulated wries |
1 |
0.75-1.0 |
300/500 |
JB8734.2 |
BLV |
AL-core PVC insulated wries |
1 |
2.5-400 |
450/750 |
|
BVR |
CU-core PVC insulated soft wries |
1 |
2.5-70 |
450/750 |
|
BVV |
CU-core PVCinsulated and sheathed circle type wries |
1 |
0.75-10 |
300/500 |
JB8734.2 |
BLVV |
AL-core PVC insulated and sheathed circle type cable |
1 |
2.5-10 |
300/500 |
|
BVVB |
CU-core PVC insulated and sheathed Flat type cable |
2,3 |
0.75-10 |
300/500 |
|
BLVVB |
AL-core PVC insulated and sheade Flat type cable |
2,3 |
2.5-10 |
300/500 |
|
RVVP |
CU-core PVC insulated and sheathed the metallic shielded soft cable |
1-24 |
0.08-2.5 |
300/500 |
JB8734.5 |
...
