2019 Year Aobest Bare AAAC Cable Aluminium Alloy Bare Conductor photo-3
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2001
Annual Export Value:
US$1.5 Million - US$2.5 Million
Contact Supplier Request Quote Chat Now
Zhengzhou Aobest Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

AAAC (All Aluminum Alloy Conductor)

 We can supply this conductor according to different recognized standards, such as BS EN50182, IEC61089, ASTM B399DIN 48, customer special specification also can be satisfied.

The data sheets below show the most common standards, British standard and IEC standard.

IEC Sizes IEC 61089

Code Number Stranding&wire diameter Approx Overall diameter Nominal Approx. Breaking Load DC Resistance at 20
area Weight
mm mm mm 2 Kg/km KN Ohm/km
16 7/1.83 5.49 18.4 50.4 5.43 1.7896
25 7/2.29 6.86 28.8 78.7 8.49 1.1453
40 7/2.89 8.68 46 125.9 13.58 0.7158
63 7/3.63 10.9 72.5 198.3 21.39 0.4545
100 19/2.78 13.9 115 316.3 33.95 0.2877
125 19/3.10 15.5 144 395.4 42.44 0.2302
160 19/3.51 17.6 184 506.1 54.32 0.1798
200 19/3.93 19.6 230 632.7 67.91 0.1439
250 19/4.39 22 288 790.8 84.88 0.1151
315 37/3.53 24.7 363 998.9 106.95 0.0916
400 37/3.98 27.9 460 1268.4 135.81 0.0721
450 37/4.22 29.6 518 1426.9 152.79 0.0641
500 37/4.45 31.2 575 1585.5 169.76 0.0577
560 61/3.67 33 645 1778.4 190.14 0.0516
630 61/3.89 35 725 2000.7 213.9 0.0458
710 61/4.13 37.2 817 2254.8 241.07 0.0407
800 61/4.38 39.5 921 2540.6 271.62 0.0361
900 91/3.81 41.8 1036 2861.1 305.58 0.0321
1000 91/4.01 44.1 1151 3179 339.53 0.0289
1120 91/4.25 46.7 1289 3560.5 380.27 0.0258
1250 91/4.49 49.4 1439 3973.7 424.41 0.0231

2019 year aobest Bare AAAC cable aluminium alloy bare conductor2019 year aobest Bare AAAC cable aluminium alloy bare conductor

Our raw materials are drawing
 2019 year aobest Bare AAAC cable aluminium alloy bare conductor
