Underground Cables Single Core 500mm2 XLPE Insulated High Voltage Cable

Underground Cables Single Core 500mm2 XLPE Insulated High Voltage Cable thumbnail-1
Underground Cables Single Core 500mm2 XLPE Insulated High Voltage Cable photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2001
Annual Export Value:
US$1.5 Million - US$2.5 Million
Contact Supplier Request Quote Chat Now
Zhengzhou Aobest Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us


Specifications:
1.XLPE/PVC High Voltage Power Cable
2.Aluminium or Copper Conductor XLPE Insulated Armored Cable
3.0.6kV~1kV~35kV

4.Reliable quality,best price
5.Strong capacity,fast delivery

 Descriptions:

1. Application Power cables for power networks, underground, outdoors and in cable ducting.
2. Type  YJV/YJLV, YJSV/YJSLV, YJV32/YJLV32, YJSV32/YJSLV32, YJV22/YJLV22, YJSV22/YJSLV22.

3. Standards		 ASTM, BS6622, IEC etc.
4. Conductor Class 2 stranded plain copper conductor to BS EN 60228:2005 (previously BS6360)
5. Conductor      screen Semi-conducting material
6. Insulation XLPE (Cross-Linked Polyethylene) Type GP8 to BS7655
7. Insulation Screen Semi-conducting material
8. Metallic Screen ndividual and overall copper tape screen to BS6622
9. Filler PETP (Polyethylene Terephthalate) fibres
10. Separator Binding tape
11. Bedding PVC (Polyvinyl Chloride) Type TM1 to BS7655
12. Armouring Single Core: Aluminium Wire Armoured (AWA)
Multi-core: Steel Wire Armoured (SWA)
13. Sheath PVC (Polyvinyl Chloride) Type TM1 to BS7655
14. Colour Red or Black or as clients' request
15. Voltage Rating  19000/33000V
16. Temperature Rating 0°C to +90°C
underground cables single core 500mm2 XLPE insulated high voltage cable
underground cables single core 500mm2 XLPE insulated high voltage cable
underground cables single core 500mm2 XLPE insulated high voltage cable
Minimum Bending Radius:
Single Core: 15 x overall diameter
Three Core: 12 x overall diameter
(Single Core 12 x overall diameter
and 3 core 10 x overall diameter
where bands are positioned adjacent
to joint or terminations provided that the
bending is carefully controlled by the use of a former)
underground cables single core 500mm2 XLPE insulated high voltage cable
underground cables single core 500mm2 XLPE insulated high voltage cable
