Ø Touch interface displays the curve of force value in real-time.
Ø Intelligently calculate: maximum value, average value and real-time value.
Ø Units of N (Newton), KN/m, lb and g (gram) can be selected intelligently according to requirements.
Ø As testing parameters is inputted, results are obtained in the form of analyzed statistical group.
Ø Intelligent operational prompt and complete safety protection system.
Ø Micro-printer can be used with USB to connect with computer.
Ø Function of electronic accurate adjustable speed is advanced.
Ø The instrument complies with ISO, JIS, ASTM, DIN and other international standards.
StandardsGB/T 4850-2002, GB 8808, GB/T 1040.3-2006, GB/T 17200, GB/T 2790, GB/T 2791, GB/T 2792, QB/T 2358
ApplicationsBasic Applications |
Tensile Strength, Deformation Rate,Break Force,Tensile Strength at break,180° Peeling |
Extended Applications |
Shearing,90°Peeling,Heat Seal Strength,Low Speed Unwinding force, Adhesive Strength (soft), Adhesive Strength (hard) |
Test Range |
100 N (Normal) |
5 N, 30 N, 50 N (Optional) | |
Accuracy |
1%FS |
Test Speed |
1-500 mm/min (adjustable) |
Sample’s Width |
30 mm (With normal Clamp) |
50 mm (With optional Clamp) | |
Stroke |
400mm |
Power Supply |
AC220V 50Hz |
Dimension |
450mm (L)×580mm (B)×100mm (H) |
Net Weight |
40 kg |
Instrument, Universal-clamp, Test Plate
Sample Cutter, Floating Roller Clamp, Sensor, Customized clamp
Saicheng Instrument is always dedicated to the innovation and improvement of product performance and function. Therefore, technical specifications are subject to change without further notice.
