Printing Paper Thickness Measurement Tester is a high-precise thickness tester with mechanical contact method, which can be used to measure the thickness of films, sheeting, paper, corrugated paperboard, textiles, non-woven fabrics, and solid insulation materials, etc.
Features
Ø Designed as strictly following the standards of contact area and measurement pressure.
Ø Automatic rising-falling head avoids errors caused by manual operation.
Ø Two testing modes-automatic and manual are convenient for users to choose freely.
Ø The instrument is equipped with auto-sampler.
Ø Relevant parameters (e.g,sampling step, number of measurement points and sampling speed) can be set by user.
Ø Analyzed data is displayed in real-time.
Ø Standard gauge blocks for system’s calibration assured the accuracy and consistency of data.
Ø Touch interface is easier to operate and check data.
Ø Standard USB interface facilitate to transfer data.
Ø Non-standard customization is supported.
Standards
This test instrument conforms to many national and international standards:
ISO 4593, ISO 534, ISO 3034, ISO12625-3, ISO5084, GB/T 6672, GB/T 451.3, GB/T 6547, ASTM D374, ASTM D1777, ASTM D3652, ASTM D6988, ASTM F2251, TAPPI T411, BS 2782-6, DIN53370, JIS K6250, JIS K6783, JIS Z1702, BS 3983, BS 4817 FEFCO No 3, EN1942
Applications
Paper, Plastic film, Sheet, Diaphragm, Cardboard, Foil, Silicon wafers, Metal sheets, Textile, Solid electrical insulation materials, Non-woven Fabrics (e.g, baby diapers, sanitary towel and other sheeting), etc.
Technical Specifications
Test Range | 0～2 mm (Standard) |
0～6 mm (Optional) | |
12 mm (Optional) | |
Resolution | 0.1 μm |
Test Pressure | 17.5±1 KPa (Film) |
50±1 KPa (Paper) | |
Contact Area | 50 mm² (Film) |
200 mm² (Paper) | |
Customization is available. | |
Feeding Distance | 0.1～99.9 mm/s |
Dimension | 461 mm (L) × 334 mm (W) × 357 mm (H) |
Net Weight | 25 kg |
Configurations
Standard: Instrument, One standard gauge block
Optional: Professional Software, Communication Cable, Measuring Head,Weights
