Oil-resistant and cold-resistant cable is an anti-static and oil-resistant special measuring cable, anti-static and oil-resistant special measuring cable, which is composed of multi-strand copper conductor, polyfluoride plastic insulation, TPV thermoplastic elastomer sheath, galvanized steel wire carrying reinforcement layer, polyurethane-based outer protection. The sleeve is composed of a polyfluoride plastic insulating material extruded outside the multi-strand copper conductor, and the TPV thermoplastic elastomer sheath is extruded outside the multi-core cable, and the galvanized steel wire is wrapped in the TPV thermoplastic elastomer sheath to carry the reinforcing layer. The galvanized steel wire carries the reinforced outer layer of the urethane-based outer sheath.
performance
Anti-oil, wear-resistant, low temperature resistance, ozone resistance, acid and alkali resistance, aging resistance, radiation resistance, etc. It is the best external material for oil and cold resistant cables.
Application
Widely used in industrial machinery equipment, various industrial sensors, transmission and transmission control systems, testing instruments, electronic equipment, household appliances, electromechanical, kitchen and other equipment, for the environment, oil and other occasions of power supply, signal connection. Applicable to metallurgical, petroleum, chemical and power plants and other industrial and mining enterprises, under high temperature conditions and harsh environments (such as acid, alkali, oil and water low temperature conditions) as a connection line of various electrical appliances, instruments and automatic devices, for AC rated voltage 450 /750 volts and below for control, monitoring and protection circuit installations.
Main structure
Conductor: Multi-strand fine-stranded oxygen-free copper wire, in line with VDE0295, CLASS 6
Insulation: special mixed PVC insulation/PUR
Sheath: Specially modified PVC sheath/PUR, strong extrusion production.
rated voltage: 300/500V
Test voltage: 2500V
Operating temperature range: Fixed installation: -40°C to +70°C
Mobile installation: - 5 ° C to +70 ° C.
Minimum bending radius: Fixed installation: 4 × cable outer diameter;
Mobile installation: 15 x cable outer diameter.
1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. 24 hours service
4. after sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.
