Spring Loaded Cable Reel Drum/spring Loaded Cable Retractor Low Voltage Flexible Retractable Spiral Spring Coiled Cable
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
2005
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Spiral Retractable Coil Network Cat5e Patch Cable Low Voltage Flexible Retractable Spiral Spring Coiled CableNegotiableMOQ: 1 -
Spiral Microphone Cable/spiral Power Cable Low Voltage Flexible Retractable Spiral Spring Coiled CableNegotiableMOQ: 1
-
Spiral Cord Coiled Cable Spring Wire/spiral Electric Cable Low Voltage Flexible Retractable Spiral Spring Coiled CableNegotiableMOQ: 1
-
Spiral Coiled Ethernet Cable/spiral Coiled Wire Cable Low Voltage Flexible Retractable Spiral Spring Coiled CableNegotiableMOQ: 1
-
Spiral Cable Power Cord/spiral Cable Protector Low Voltage Flexible Retractable Spiral Spring Coiled CableNegotiableMOQ: 1
Product Description
spring loaded cable reel drum/spring loaded cable retractor Low Voltage Flexible Retractable Spiral Spring Coiled Cable
Application
Spiral cables are mainly used for the most rigorous situations such as intensive use robots, electric doors, heavy duty machine, lifting ramps and drilling machines. They are suitable for both indoor and outdoor use and will provide long service life in very high duty applications. PUR outer sheath has resistance to abrasion, mineral oil, cooling liquid and gas. Additionally, PUR can be used all day long and anti microorganism and hydrolysis.
Construction
Conductor: Fine stranded bare/tinned copper
Insulation: PE (polyethylene)
Core color: TBD acc. to DIN 47100 standard. Wire gauge>0.5mm2, black insulation and white serial number with GR-YE protective conductor.
Outer sheath: PUR (polyurethane)
Sheath color: Grey(RAL 7001), Black(RAL 9005) or Orange(RAL 2003)
Technical data
Rated voltage: 300V ( <0.34mm2), 300/500V (≥0.5mm2)
Testing volatge: 1200V ( <0.34mm2), 3000V (≥0.5mm2)
Temperature range: -5℃ till +70℃
Operating temperature: -5℃ till +70℃
Bending radius: Fixed installation 5xOD, In motion 7xOD
Additional information
Closed spiral length: max 4000mm
Extended spiral length: up to 4x closed length
Cable tails: normally ends 200mm / 200mm. Straight ends available up to 25m
Spiral OD: varies from 40mm to 150mm
Spiral ID: varies from 20mm to 130mm
Above information is norminal and it can be adjusted as per your requirements.
