Product Name |
24 core spreaderflex cable pendent cable for crane |
Article Number |
DERUL-A783 rov tether/pipe crawler cable/robot cable/drag chain cable |
Constructure |
Conductor+insulator+sheath+shield |
Conductor |
Copper/sliver/aluminum... |
Insulation |
PVC/PE/PUR/TPU/TPE/PU/TPEE... |
Shielding |
Braided tinned copper |
Voltage |
300-1000V |
Size |
According to customer requirements |
Color |
According to customer requirements |
Applications |
ROV tether/UAV tether/drag chain/crane/elevator/underwater robot... |
MOQ |
Depends on the specifications you need |
Sample term |
Free sample on stock with freight collect |
Product lead time |
3-10 working days after deposit received |
Shipping lead time |
3-5 working days by DHL/FEDEX/TNT/UPS... |
Loading port |
FOB Shanghai |
Payment term |
T/T, Paypal, 30% edposit advanced, 70% balance before shippment |
Application
Flexiable low voltage power and control cable,for use on festoon systems and for connecting moveable parts of machine tools, materials handing equipment,etc.,associated with high mechanical stress and frequent bending during operation and for bending in one plane only.
Construction
Conductor: Fine stranded bare/tinned copper
Insulation: PE (polyethylene)
Core color: TBD acc. to DIN 47100 standard.
Outer sheath: PUR (polyurethane)
Sheath color: Grey(RAL 7001), Black(RAL 9005) or Orange(RAL 2003)
Technical data
Rated voltage: 300/500V(600V)
Max.permissble operating voltage AC: 0.7/1.2KV
Max.permissble operating voltage DC: 0.9/1.8KV
AC Test Voltage: 4KV(5 Min.)
Temperature range: -40℃ till +80℃
Operating temperature: -40℃ till +80℃
Max. tensile load on the conductor: 15N/mm2
Min.bending radius: Acc.to VDE 0298 part 3
Travel speed: Trollry(festoon system):180m/min
Additional information
coresNO.×cross section
conductor diamater max.mm
height
min.mm-
max.mm
width
min.mm-
max.mm
bending radius free moving min.mm
weight kg/km
carrying capacity
3×1.5
1.5
5.7-6.2
11.7-12.5
19
130
24
4×50
9.5
18-19
56-58
95
2830
212
5×4
2.8
8.5-9
28.9-31.2
36
510
43
12×1.5(c)
1.5
7.4-8
51.7-55
97
360
24
4×95（c）
12.9
24.2-27.2
78.7-83.7
136
5950
316
Flexiable low voltage power and control cable,for use on festoon systems and for connecting moveable parts of machine tools, materials handing equipment,etc.,associated with high mechanical stress and frequent bending during operation and for bending in one plane only.
Construction
Conductor: Fine stranded bare/tinned copper
Insulation: PE (polyethylene)
Core color: TBD acc. to DIN 47100 standard.
Outer sheath: PUR (polyurethane)
Sheath color: Grey(RAL 7001), Black(RAL 9005) or Orange(RAL 2003)
Technical data
Max.permissble operating voltage AC: 0.7/1.2KV
Max.permissble operating voltage DC: 0.9/1.8KV
AC Test Voltage: 4KV(5 Min.)
Temperature range: -40℃ till +80℃
Operating temperature: -40℃ till +80℃
Max. tensile load on the conductor: 15N/mm2
Min.bending radius: Acc.to VDE 0298 part 3
Travel speed: Trollry(festoon system):180m/min
Additional information
| coresNO.×cross section | conductor diamater max.mm | height min.mm- max.mm |
width min.mm- max.mm |
bending radius free moving min.mm | weight kg/km | carrying capacity |
| 3×1.5 | 1.5 | 5.7-6.2 | 11.7-12.5 | 19 | 130 | 24 |
| 4×50 | 9.5 | 18-19 | 56-58 | 95 | 2830 | 212 |
| 5×4 | 2.8 | 8.5-9 | 28.9-31.2 | 36 | 510 | 43 |
| 12×1.5(c) | 1.5 | 7.4-8 | 51.7-55 | 97 | 360 | 24 |
| 4×95（c） | 12.9 | 24.2-27.2 | 78.7-83.7 | 136 | 5950 | 316 |
Derul Cable (Shanghai) Co., Ltd,
1. Flexible cable series ( drag chain cable, servo cable, welding cable, converter cable and etc )
2. Drum cable series ( elevator traveling cable, reeling cable, spreader cable, cable for oil drilling platform, cable for wind power and etc )
3. Robot cable series ( cable for industrial robot, ROV, pipe inspection crawler, underwater camera, manipulator arm and etc )
4. Flat cable series ( cable for elevator, acid and alkali resistant cable, cable for plating equip and etc )
All products we produce conform to Europe CE Standard (CONFORMITEEUROPEENNE) and ISO9001:2015 quality management system. Derul Cable, as a renowned cable manufacturer in China, is able to develop and customize various cables complying with customers' requirements.
Q1: What can I get from your company?
A1: Our company, Derul Cable is a professional company that specialized in different cables specially in ROV cables, flexible cables, underwater cables, flat elevator cables and so on. We can not only provide you qualified products but also excellent services. Let us help you to grow your business!
Q2: What is your MOQ?
A2: If we have products in our stock, there is no MOQ. For customized cables, the MOQ is 100 meters or more. It depends on the specifications you need.
Q3: How can you ensure your product quality?
A3: We can provide samples before you place the bulk order. So you can check the product quality through the sample. We are a company that aims to provide high quality and good service to our customers. The products are using qualified raw materials. Our products are under CE requirements.
Q4: Do you do OEM service?
A4: Yes, we can customied the products for our customers. Please advise the detailed specifications you need. We will evaluate your needs and give our professional suggestions and best offer.
Q5: When can I receive the goods after I payed?
A5: Usually it will take 7 days to receive the goods.
Q6: What if I payed the money and you don't send the goods to me?
A6: It will never happens to you. We have trade assurance order on alibaba which can guarantee your order from beginning to the end.
