Home > Manufacturing & Processing Machinery > Stone Processing Machinery > Stone Cutting Machine > Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center

Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center

Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center thumbnail-1
Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center thumbnail-2
Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center thumbnail-3
Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center thumbnail-4
Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center photo-1
Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center photo-2
Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center photo-3
Quartz Stone Cutting Machine GSY-3015ATC Cnc Stone Machinery Router Marble Granite Edge Profiling Polishing Center photo-4
US$ 15500 - 16900 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Ganger
Place of Origin:
China
Model Number:
GSY-3015ATC
Contact Supplier Request Quote Chat Now
Jinan Ganger Cnc Technology Co.,ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Ganger
Place of Origin China
Model Number GSY-3015ATC
Type CNC Router
Use Granite
Certification CE
After-sales Service Provided Overseas third-party support available
Warranty 1 year
Weight 2T
Dimension(L*W*H) 5400mm*2250mm*2250mm
Production Capacity 30sets/month
Condition New
Voltage 380V
Power(W) 38KW

Features: Finish two countertop at same time,  in 3 steps: cutting, edge profiling, polishing.  Change tools automatically.

Example design:( Finish two pcs work at one time)

1. Cutting the big hole 1;

2. Drilling three small hole 2.3.4;

3. And then first cutting,  first polish and second polish for edge 5;

4. Theoretically, finish this the whole working need about 30 mins.





Applicable industry and applicable materials

Applicable industries: Widely used in CNC processing and production of basins, cabinet countertops, bathroom countertops, bar counters, kitchen countertops, washstands, marble walls, dining tables, coffee tables, window sills, door pockets, etc.

Applicable materials: widely used in granite, quartz stone, artificial stone, marble and other stone.



Technical parameters

Model

GSY-3015ATC

X/Y/Z Axis working size

3000*1500*430mm

Working table

Aluminum profile with T-slot and water tank

X/Y/Z Axis transmission

X/Y Axis helical Gear and rack, Z Axis Ball screw

Spindle power

ATC spindle 7.5KW(optional)

Max spindle speed

0-12000rpm

ATC type and capacity

Linear ATC, 12 tools

Driver motor

Siemens Servo

Control system

Siemens 828D

Gross weight

4500KGS

Quality Control
1.1  In the processing of production, our professional technical engineers inspect the processing to ensure the quality of products
1.2  Each machines will run around 24 hours and tested about 8 hours before delivery to ensure
normal using in your workshop .


Guarantee & After sale services
2.1  Free training available here China or teaching video with machine to your Country
2.2  12 months guarantee under normal use & Lifetime maintenance free of charge.
2.3  Spare parts shall be changed free of charge if any problem during the warranty period
2.4  Consumable parts will be offered at agency price when replacement needed.

OEM service available
3.1  XYZ working size customized according to your requirement
3.2  Main spare parts: motor,system,inverter choose as your choice
3.3  Machine brand and oil painting customized (agent available or MOQ 10 sets)

Delivery
4.1 Standard model
3 axis cnc router 4 axis cnc router 5 axis cnc router around 90 working days
4.2  Customized model
Depends on special spare parts delivery time

Payment terms
5.1  T/T in advance
5.2  West union: Available when amount less than 1000$, banking charges paid by buyer
5.3  LC: Available when amount more than 30000$,
      LC draft should be sent to confirm before Original LC made.


With near 16 years rich experience, we assure you perfect machine quality and after sale service.
Based on mature technical assurance, my cnc router will be surely finish satisfactory work for you.
I am Layne for your service now, any questions or requirement about machine ,directly contact me here online ,or email as you like.
I will always be ready to give what you need
Just Start right now.

Product Tags: quartz stone cutting machine , stone machinery router , marble granite edge profiling polishing center
