5 axis cnc bridge saw polishing milling bridge saw cutter machine GQ-3220D granite slab bridge saw stone machinery
- 30 Set / Sets per Month
- Qingdao Port
- T/T L/C Other
- 30 days
- CNC Stone Router Engraving Machine Marble Granite Carving Milling Edge Cutting Machinery
- Heavy Duty Marble Carving CNC Stone Engraving Machine
- CNC Laser Cutting Portable Band Sawing Carving Marble Granite Stone CNC Milling Machines
- Heavy Duty CNC Stone Carving Granite Stone Slab Cutting Machines HLSD-1525-3D
- HLSD-1525-3D High Quality Economic Stone CNC Carving Machine to Manufacture Artificial Stone for Engraving Granite Artificial Stone
- CNC Router Laser Engraver Headstone Tombstone Engraving Equipment Stone Plate Carving Machine for Cutting Slate Marble Granite
Product Details
Brand Name: | Ganger | Place of Origin: | China | Model Number: | GQ-3220D |
Type: | Bridge Saw | Use: | Granite | Certification: | CE |
After-sales Service Provided: | Overseas third-party support available | Warranty: | 1 year | Weight: | 4500KG |
Dimension(L*W*H): | 5500mm*2200mm*2200mm | Production Capacity: | 30sets/month | Voltage: | 380V |
Power(W): | 29KW |
Product Description
Features:
1. XYZAC five axis, A axis 0 to 90 degrees automatic rotation, C axis 0 to 360 degrees automatic rotation.
2. Cutting straight line, circular, arc, grid point.
3. Slotting, edging, beveling, chamfering and cutting;
4. Curved surface, blade milling, cutting holes, and contouring are all available;
5. Double suction moving, Option vacuum feets;
6. By infrared ray to confirm the position of the workpiece;
7. Intelligent on-demand typesetting, saving time and materials.
Applicable industry & material
Applicable industry: sintered stone application industry, fabricated building materials industry, home decoration materials
industry, cutting marble, artificial stone, quartz stone and other materials.
Applicable material: Dekton, sintered stone, quartzstone, granite, ceramic plate, porcelain, rock slab and all stone stuffs etc.
Technical Parameters
Model : GQ-3220D
X/Y/Z Axis working size : 3200*2000*500mm
Diameter of blade : 350mm
Working table size : 3200x2000mm
Blade motor power : 15KW
Total power : 29kw
Blade rotation speed : 3000rpm-6000rpm (Optional, adjustable)
A axis rotation angle : 0°-90°
C axis rotation angle : 0°-360°
Table tilting : 0°-85°
Suction moving : Double suction
Vacuum feets : Option
Control system : TAIWAN control system
Gross weight : 4500KGS
Quality Control
1.1 In the processing of production, our professional technical engineers inspect the processing to ensure the quality of products
1.2 Each machines will run around 24 hours and tested about 8 hours before delivery to ensure
normal using in your workshop .
Guarantee & After sale services
2.1 Free training available here China or teaching video with machine to your Country
2.2 12 months guarantee under normal use & Lifetime maintenance free of charge.
2.3 Spare parts shall be changed free of charge if any problem during the warranty period
2.4 Consumable parts will be offered at agency price when replacement needed.
OEM service available
3.1 XYZ working size customized according to your requirement
3.2 Main spare parts: motor,system,inverter choose as your choice
3.3 Machine brand and oil painting customized (agent available or MOQ 10 sets)
Delivery
4.1 Standard model
3 axis cnc router <=12 working days
4 axis cnc router <=20 working days
5 axis cnc router around 90 working days
4.2 Customized model
Depends on special spare parts delivery time
Payment terms
5.1 T/T in advance
5.2 West union: Available when amount less than 1000$, banking charges paid by buyer
5.3 LC: Available when amount more than 30000$,
LC draft should be sent to confirm before Original LC made.
With near 16 years rich experience, we assure you perfect machine quality and after sale service.
Based on mature technical assurance, my cnc router will be surely finish satisfactory work for you.
I am Layne for your service now, any questions or requirement about machine ,directly contact me here online ,or email as you like.
I will always be ready to give what you need
Just Start right now.
