150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox

150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox thumbnail-1
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox thumbnail-2
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox thumbnail-3
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox thumbnail-4
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox thumbnail-5
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox photo-1
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox photo-2
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox photo-3
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox photo-4
150W 36V 4.2A IP67 Hermetic LED Plastic Power Supply for Led Modules Led Strips Lightbox photo-5
US$ 12 - 14 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Brand Name:
AMCFLEX
Place of Origin:
China
Model Number:
APVM-150-36
Contact Supplier Request Quote Chat Now
Changzhou AMCFLEX Technology Co Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name AMCFLEX
Place of Origin China
Model Number APVM-150-36
Output Power 101 - 200W
Output Type Single
Output Current 4.2A
Output Frequency 50/60hz
Output Voltage 36V
Input Voltage 220V

Model: APVM-150-36

Constant voltage LED Power Supply.

Input Voltage: 200-240VAC 47-63Hz,1.5A max

Output Voltage: 36V

Output Current:  4.2A

Output Rated Power: 150W max

Inrush Current: 70 Amps max. at 230VAC/50Hz,full load

No Load Power Consumption: ＜0.5W

TC: 85 ℃, Ta:50 ℃

Protections: Short Circuit /Over Current /Over Voltage

/over temperature protection

Short Circuit Protection (SCP) Yes,hiccup mode, auto-recovery

Over Voltage Protection (OVP): Yes,hiccup mode, auto-recovery

Over Current Protection (OCP): Yes,hiccup mode, auto-recovery

Working TEMP.: -30°C-to 70°C

Working Humidity: 10%-90% RH non-condensing

StorageTEMP.,Humidity and altitude: -40℃ ~+70°C ambient

temperature and a 5% to 95% relative humidity range throughout

an altitude range of -60 meters to +5000 meters AMSL.

Certificates and approvals: CE CB SELV ROHS

MTBF: 100Khours minimum at full load at 25℃ ambient

Dimension: 190 x 52x 37mm (L x W x H)

Packing: 0.7Kg;20pcs/15Kg/0.02CBM


Model NO

Input Voltage

Output Voltage

Output current

Output Power

Efficiency

Dimension/mm

APVM-150-12

200-240Vac

12V

12.0A

144W

91%

190x52x37

APVM-150-24

200-240Vac

24V

6.25A

150W

91%

190x52x37

APVM-150-36

200-240Vac

36V

4.16A

150W

92%

190x52x37

APVM-150-48

200-240Vac

48V

3.125A

150W

93%

190x52x37


Product Tags: Waterproof LED Power supply , LED Module Power Supply , LED Strip Power Supply , LED Transformer , Plastic housing power supply
