Model:APMS-100-48
Technical Specs:
Rated Output voltage: 48VDC
Rated Output Current:2.1A
Rated Output Power: 100W Max
Efficiency>91%
Line Regulation:±0.5%
Load Regulation:±1.5%
Voltage tolerance:±3%
2. Input Parameters
Rated Input voltage:200-277VAC
Input voltage range:176-305VAC, 47-63hz
Input Current Max:1.0A
Inrush Current
Power Factor>0.95
THD
3. Protection
Overload
Short Circuit
Over voltage
Over Temperature
4. Environment
Operating Temperature range:-40 to +80℃
Storage Temperature range:-45 to +80 ℃
Humidity: 10～95%
Waterproof Level:IP67
5. Safety Standards
UL8750, IEC/EN61347-1,EN61347-2-13,EN62368, GB19510.1,
GB19510.14, IP67 Approved
Withstand voltage: I/P-O/P:3KV
EMI,EMS
EN55015(CISPR15), GB17743, EN61000-3-2 , Class C, EN61000-4-2,
8KV air ; Level 2, 4KV contact, EN61000-4-3, EN61000-4-4,
EN61000-4-5，4KV/Line-Line 6KV/Line-Earth, EN61000-4-6
6. Others
MTBF>200Khours
Dimension:150(L)*51 (W)*38(H)mm
Packing: 0.65KG/PC, 350x310x260mm, 20pcs /14.5Kg / 0.02CBM /CTN
CV+CC Hybrid Output | ||||||
Model NO |
Input Voltage |
Output Voltage |
Output current |
Output Power |
Efficiency |
Dimension/mm |
APMS-120-24 |
200-277Vac |
24V |
0-5.0A |
0-120W |
92% |
156x63x40 |
APMS-120-36 |
200-277Vac |
36V |
0-3.33A |
0-120W |
92% |
156x63x40 |
APMS-120-48 |
200-277Vac |
48V |
0-2.5A |
0-120W |
93% |
156x63x40 |
APMS-120-54 |
200-277Vac |
54V |
0-2.22A |
0-120W |
94% |
156x63x40 |
