75W 54V 1.38A Waterproof Strip Power Supply

75W 54V 1.38A Waterproof Strip Power Supply thumbnail-1
75W 54V 1.38A Waterproof Strip Power Supply photo-1
US$ 10 - 12 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Brand Name:
AMCFLEX
Place of Origin:
China
Model Number:
APMS-75-54
Contact Supplier Request Quote Chat Now
Changzhou AMCFLEX Technology Co Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name AMCFLEX
Place of Origin China
Model Number APMS-75-54
Output Power Other, 75W
Output Type Single
Output Current 1.38A
Output Frequency 50/60hz
Output Voltage 54V
Input Voltage 220V

Model:APMS-75-54

Technical Specs:

1.Output Parameters

Rated Output voltage: 54VDC

Rated Output Current: 1.38A

Rated Output Power:75W Max

Efficiency>90%

Line Regulation:±0.5%

Load Regulation:±1.5%

Voltage tolerance:±3%


2.  Input Parameters

Rated Input voltage:200-277VAC

Input voltage range:176-305VAC, 47-63hz

Input Current Max:0.5A

Inrush Current

Power Factor>0.95

THD


3. Protection

Overload

Short Circuit


4. Environment

Operating Temperature range:-40 to +80℃

Storage Temperature range:-45 to +80 ℃

Humidity: 10～95%

Waterproof Level:IP67


5. Safety Standards

UL8750, IEC/EN61347-1,EN61347-2-13,EN62368, GB19510.1,

GB19510.14, IP67 Approved

Withstand voltage: I/P-O/P:3KV


EMI,EMS

EN55015(CISPR15), GB17743, EN61000-3-2 , Class C, EN61000-4-2,

8KV air ; Level 2, 4KV contact, EN61000-4-3, EN61000-4-4,

EN61000-4-5，4KV/Line-Line 6KV/Line-Earth, EN61000-4-6


6. Others

MTBF>200Khours

Dimension:115(L)*64 (W)*37(H)mm

Packing: 0.55KG/PC, 350 x 310 x 260 mm, 24pcs /14.7Kg /0.02CBM/CTN

Constant Voltage Output

Model NO

Input Voltage

Output Voltage

Output current

Output Power

Efficiency

Dimension/mm

APMS-75-24

200-277Vac

24V

0-3.125A

0-75W

88%

114x64x37

APMS-75-36

200-277Vac

36V

0-2.08A

0-75W

88%

114x64x37

APMS-75-48

200-277Vac

48V

0-1.56A

0-75W

89%

114x64x37

APMS-75-54

200-277Vac

54V

0-1.38A

0-75W

90%

114x64x37
