BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire

Dongguan XSD Cable Technology Co., Ltd.
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire thumbnail-1
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire thumbnail-2
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire thumbnail-3
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire thumbnail-4
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire thumbnail-5
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire photo-1
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire photo-2
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire photo-3
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire photo-4
BV Bvr Hook up Wire PVC Flexible Sheathed Flat Electrical Cable Wire photo-5
US$ 0.01 - 1 MOQ: 6100 Meters
Key Specifications
Get Latest Price
Place of Origin:
China
Type:
Insulated
Application:
Other, Internal Wiring of Appliance, Installation
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Type Insulated
Application Other, Internal Wiring of Appliance, Installation
Insulation Material PVC
Conductor Material Copper
Conductor Type Other, Tinned or Bare, Stranded or Solid Copper

IEC60227 BV RV BVR RVV RVB AVVR RVVP Electric Wire and Cable Housing Wire Building Wire Installation Wire Hookup Wire

-Rated temperature: 70ºC
-Rated voltage: 300V/300V; 300V/500V; 450V/750V
-Reference Standard: GB/T5023.3; GB/T 5023.5-2008; IEC 60227
-Flame test: IEC 60332
-Uniform insulation thickness of wire to ensure easy stripping and cutting.
-For internal wiring of electronic and electrical equipment and appliance.


Product Parameters


Code Designation
by IEC		Code Designation
by GB		Rated VoltageRated  TemperatureNominal crosssection(mm²)DescriptionApplication
60227 IEC 01BV450V/750V0°C~70°C1.5 to 35mm2Copper Conductor PVC Insulated Rigid CableFixed laid indoors instrument etc.
60227 IEC 05BVR450V/750V0°C~70°C2.5 to 35mm2Copper Conductor PVC Insulated Semi-Flexible CableFor laying permanent place where flexible required
60227 IEC 02RV450V/750V0°C~70°C1.5 to 35mm2Copper conductor PVC Insulated Flexible Connector CableMainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required
60227 IEC 06RV300V/500V0°C~70°C0.5 to 1mm2
60227 IEC 52RVV300V/300V0°C~70°C0.5 to 0.75mm2
(2 to 3 cores)		Copper conductor PVC Insulated and PVC Sheathed Round Flexible Connector Cable
60227 IEC 53RVV300V/500V0°C~70°C0.75 to 2.5mm2
(2 to 5 cores)
4mm2
(3 to 5 cores)
0.75 to 2.5mm2
(6 cores)
0.75 to 1.5mm2
(7 to 8 cores)
0.75 to 1mm2
(10 to 24 cores)
60227 IEC 42RVB300V/300V0°C~70°C0.5 to 4mm2
(2 cores)		Copper conductor PVC Insulated Flat Flexible Connector Cable
N/ARVVP300/300V0°C~70°C0.08 to 1.5mm2
(2 cores)		PVC Insulated Wire and Shielded Wire for InstallationFor Installation
0.12 to 1.5mm2
(3 cores)
0.12 to 0.4mm2
(4 to 24 cores)
AVVR300/300V0°C~70°C0.08 to 0.4mm2
(2 cores)
0.12 to 0.4mm2
(4 to 24 cores)


Certifications

UL AWM Listing(Line Card)


SHENZHEN SINGDER INSULATION MATERIALS CO LTD (E484953)
Table of Recognized Styles
Single-conductor, thermoplastic insulation.
1007106113301332143015711026910702
10151185133113331569158910368
Multiple-conductor, thermoplastic insulation.
246426482678200802101621513

2468265127252027621370


Single-conductor, thermoset insulation.
31733271332133863656


3266330233853619



Multiple-conductor, thermoset insulation.
4478







DONGGUAN XSD CABLE TECHNOLOGY CO LTD (E506386)
Table of Recognized Styles
Single-conductor, thermoplastic insulation.
10071015106115691007010368

10131032118515711026911627

Multiple-conductor, thermoplastic insulation.
246424682517254726512725283520276
Single-conductor, thermoset insulation.
31733266328933213386


31963271330233853656



About us

Dongguan XSD Cable Technology Co., Ltd (subsidiary of Shenzhen Singder Insulation Materials Co., Ltd) is a Chinese professional manufacturer with "ISO9001, IATF16949, UL, cUL, CCC" approved in Dongguan city next to Shenzhen and Guangzhou.


★Main Products: UL/cUL AWM Wires&Cables, Automotive Wire, Industrial Wire, Hook-up&Lead Wire, Solar Cable(PV Wire), Heating Wire, FFC Wire, Flat Ribbon Cable, BV, RV, BVR, RVV, RVB, AVVR, RVVP, USB Cable, HDMI, DVI, VGA, Cable Assembly, Wire Harness and so on.


★Insulation Materials: PVC/PE/XLPE/LSZH/PTFE/PFA/FEP/SILICONE RUBBER/TPU/TPE and so on.
