CFP-100G-ER4= Overview
The Cisco® 100GBASE CFP modules offer customers 100 Gigabit Ethernet connectivity options for data center networking, enterprise core aggregation, and service provider transport applications.
- CFP-100G-ER4= Specification
-
CFP-100G-ER4= Specification Description
Cisco 100GBASE-ER4 CFP Module for SMF (
Dimensions
144.8 x 82 x 13.6 mm
Wavelength (nm)
1310 band (LAN-WDM)
Fiber Type
SMF
Core Size (microns)
G.652
Modal Bandwidth (MHz-km)
\
Max Distance
40 km
Digital Optical Monitoring (DOM)
Yes
Average Transmit Power (dBm)
Max:2.9 per lane
Min:-2.9 per lane
Average Receive Power (dBm)
Max:4.5 per lane
Min:-20.9 per lane
Transmit and Receive Wavelength
Four lanes, 1295.6 nm, 1300.1 nm, 1304.6 nm, and 1309.1 nm
Environmental Conditions and Power Requirements
Operating temperature
32 and 158°F (0 to 70°C)
Storage temperature
-40 to 185° F (-40 to 85° C)
Maximum power consumption
24 W
