High Quality Image Measuring Instrument /Laser Measuring Instrument Price

Device parameters:

Stroke size: 300-1200mm

Measuring space: 100-1200mm

Bearing weight: 200-500kg

725

1400

MPEe: 3.5-3.5(um)

Scale resolution: 0.4um

Flow/supply pressure: 120N1/min 0.45Mpa

Temperature: 20±2℃

Equipment introduction:

It is produced by relying on computer screen measurement technology and powerful software capabilities of spatial geometric operations. After the computer is installed with special control and graphic measurement software, it becomes the measurement brain with the soul of the software, which is the main body of the entire device. It can quickly read the displacement value of the optical scale, and obtain the desired result in an instant through software module calculations based on space geometry; and generate graphics on the screen for the operator to compare images and shadows, so as to intuitively distinguish Possible deviations in measurement results.

3D image measuring instrument/Size measuring instrument

Equipment usage: This equipment is widely used in mobile phone accessories, computer accessories, home appliances accessories, machinery accessories, precision hardware accessories, precision metallurgy, precision bearings, circuit boards, plastic products, molds, terminals, connectors, clocks, instrument parts , Auto parts, etc.

features:

The image measuring instrument is composed of a high-resolution CCD color lens, a continuous zoom objective lens, a color display, a video cross-line display, a precision grating ruler, a multi-function data processor, data measurement software and a high-precision workbench structure. High-precision optical image measuring instrument.

Product advantages:

All core components are imported with original packaging.

 All three axes are made of high-precision natural granite.

 All three-axis guide rails adopt high-precision self-cleaning air bearings, which make the movement more stable and the guide rails are subject to wear.

 All three axes adopt high-precision imported grating ruler.

 The X-direction adopts precision triangular beam technology, which has a lower center of gravity, a mass-rigidity ratio, and a more reliable movement than rectangular beams.

 The Y-direction adopts an integral dovetail guide rail, which reduces the weight of the machine while effectively eliminating movement torsion, ensuring measurement accuracy and stability.

 The industry benchmark dedicated Rational DMIS automatic dynamic measurement software is easy to operate and reliable.

 In line with ergonomic design.
