Projector for charpy specimen from China
1. Application :
CTS-50 is a kind of special projector, which amplifies and projects the U or V-shaped profiles of the measured parts to the screen to check their profiles and shapes with high accuracy utilizing the optical projection method. It is widely used to check the U and V-shaped notch of the impact specimen with the features of easy operation, simple structure, direct inspection and high effectiveness.
2. Main Technical Parameters :
Diameter of the Screen | 200mm |
Magnification of the instrument | 50X |
Objective magnification | 2.5X |
Working table square shape | 110x125mm |
Diameter of round worktable | 90mm |
Diameter of working screen | 70mm |
Stroke of working table | Longitude: ±10mm,Latitude: ±10mm, Rise and fall: ±12mm |
Eye-field diameter | 3.8mm |
Working distance | 22.89mm |
Scope of revolving of the worktable | 360° |
Power supply | 220V,50HZ,150W |
Dimension | 515×224×603mm |
Light source(tungsten halogen lamp) | 12V,100W |
Weight | 18kg |
1. Delivery date: 7 days after receiving payment .
2. Payment terms: T/T100% before shipment .
3. Packages: Plywood Cases .
