CTS-50 Impact Specimen U/V Notch Projector
1.Function
CST-50 impact specimen U/V notch projector is supplemental equipment for impact test, mainly used to check the accuracy of impact specimen U/V notch. Users can put the notched specimen on projector working table and compare the projection image with the standard plate to identify the quality of the specimen notch.
2.Features
1) Meets the standards of GB/T229-94 “Metal Charpy Impact Test Method” and ASTM, E23 ,ISO148-2006 for impact sample notch;
2) Adopts optical projection method;
3) Easy to operate, high efficiency, direct visual comparison;
4) The only feasible and reliable equipment to ensure the check quality.
3.Main Technical Parameters
Projector screen diameter |
200mm |
Multiplying times |
50* |
Stroke of working table |
Vertical: ±10mm, Lateral: ±10MM, Up and down:12mm |
Revolving range of the working table |
360° |
Power supply |
220V,50HZ,150W |
Dimension |
515*224*603 |
Light source(tungsten halogen lamp) |
12V,100W |
Weight |
18kg |
4. Application
CTS-50 impact specimen U/V notch projector, as the special optical instrument in impact test, is widely used in many industries and areas including, metallurgy, steel plates, steel pipes, wind power generation, hardware, metal, casting, pumps, valves, solar energy, war industry, fasteners, diesel engines, electric power, iron towers, railways, shipbuilding, iron tower, machinery manufacturing, automotive industry, aerospace industry, physical and chemical laboratory and scientific research.
Impact Testing Equipment Pics:
