Working principle
When the microwave passes through the water-containing material and the dry material, the propagation speed and intensity of the microwave in the propagation direction will change differently, and the water-containing material will slow down the propagation speed and the intensity of the microwave. The measuring principle of the equipment is to calculate the moisture content in the material by detecting the changes of these two physical properties of the microwave after passing through the material.
Applied materials
Microwave water measurement technology is applicable to many non-conducting substances, including (but not limited to) coal, alumina, wood, sugar, bagasse, sand, mineral powder, food, chemicals, etc.
Features
■ Non-contact measurement: no wear, no interference, little maintenance
■ Fast real-time results: a response speed of milliseconds can be achieved
■ Fully automatic operation: automatically check the operating status of each part of the unit
■ Humanized operation interface: to meet the different needs of users
■ Convenient installation and commissioning: The type can be selected according to the on-site installation environment
■ Safe and pollution-free: high safety and reliability, no radioactive sources
■ Technical support and service: Provide timely service and detailed technical feedback
■ Wide range of applications: almost all substances can be measured
Specifications
Controller | ||
Measure range |
0%~50%, ±0.5%, both may vary per different detect material |
|
Display |
Moisture content percentage |
|
Enclosure |
Made of cold-rolled steel plate, textured surface, polyester powder spraying. |
|
Protection degree |
IP 65 |
|
Net weight |
Approx. 17 kg |
|
Operation Temp. |
-20~ +45°C (253 ~318 K), no condensing |
|
Storage temp. |
-20 ~ +70°C (253~343 K), no condensing |
|
Display/operation |
5.7 Inch 640*480 Graphic dot matrix，65K TFT touch screen LCD |
|
Working voltage |
AC200~240 V AC, 45~65 Hz |
|
Power consumption |
Max 30W |
|
Signal output |
4~20mA |
|
Standards |
IEC61326-1, IEC61000-6-2, IEC 61010-1 |
|
Overall size |
500 x 400 x 200 mm |
|
Cable interface | ||
Cross section |
Min 1.0mm2 (main power supply) |
|
Cable interface |
5×(M18×1.5) |
|
High frequency cable |
Length 1.5-3m,50W,N interface |
|
Microwave sensor | ||
Item |
High gain directional antenna |
|
Enclosure |
Made of die-cast aluminum and epoxy coating |
|
Net weight |
2 kg |
|
Operation Temp. condition |
-20~ +55°C (253 ~323 K ), no condensing |
|
Storage Temp. |
-20 ~+70°C (253~343 K ), no condensing |
|
Input resistance |
2 x HF connector N jack, 50 Ω |
|
