Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber photo-2
Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber photo-3
Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber photo-4
Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber photo-5
Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber photo-6
US$ 1,000 - 2,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
GESTER
Place of Origin:
Fujian, China
Model Number:
GT-F50-4
Contact Supplier Request Quote Chat Now
Quanzhou GESTER Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GESTER
Place of Origin Fujian, China
Model Number GT-F50-4
Power Electronic
Usage Universal Testing Machine

Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber



Product Description

Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber

Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber



Application:



Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber is also called Salt spray test chamber. The salt spray test of Corrosion Chamber Salt Spray Tester aims at determining the product corrosion resistance test after various kinds of materials surface suffering electroplating, anodizing, painting, rust-proof oil corrosion resistance treatment.The Corrosion Chamber is suitable for neutral salt spray test (NSS) and acidic corrosion experiment (AASS, CASS).





Model:

Model

GT-F50A-1

GT-F50A-2

GT-F50A-3

GT-F50A-4

GT-F50A-5

Inside chamber dimension

60x45x40

90x60x50

120x100x50

160x100x50

200x120x60

Outside chamber dimension

107x60x118

141x88x128

190x130x140

230x140x140

270x150x150

Test chamber volume

108L

270L

600L

800L

1440L

Brine tank

15L

25L

40L

40L

40L

Power supply

AC220V1Φ10A

  AC220V1Φ15A

AC220V1Φ30A

AC220V1Φ30A

AC220V1Φ30A



Product Images:

Corrosion Testing Salt Fog Chamber Salt For Salt Mist Chamber



Key Specification

Temperature of test chamber

Brine test method(NSS ACSS)35℃±1℃

Corrosion resistance test method (CASS)50℃±1℃

Temperature of pressure barrel

Brine test method(NSS ACSS)47℃±1℃

Corrosion resistance test method (CASS)63℃±1℃

Brine concentration

5% sodium chloride solution concentration

or add copper chloride 0.26 grams per liter

in the 5% sodium chloride solution concentration.

 (CuCl2 2H2O)

Brine temperature

35℃±1℃ 50℃±1℃

Power

AC220V  50Hz

Compressed Air Pressure

1.00±0.01kgf/cm2

Spray volume

1.0~2.0ml/80cm2/h

(gather at least 16 hours, take its average)

Relative temperature of test chamber

Above 85%

PH-value

6.5~7.2 3.0~3.2

Spray method

continuous spray or intermittent spray

Temperature range

Lab temperature

35℃ -50℃( can be arbitrarily set)

Pressure barrel temperature

47℃ - 63℃( can be arbitrarily set)

Speed of temp rising

Laboratory

Room temperature →35℃  about 35 minutes

Pressure barrel

Room temperature →47℃  about 15 minutes

Temp accuracy

±1℃

Standards

CNS3627, 3885, 4159, 7669, 8886,

JIS D-0201, H-8502, H-8610,K-5400,Z-2371,

ISO 3768,3769,3770,

ASTM B-117, B-268,GB-T2423, GJB 150
